July 31, 2017
How to useLonsdorSKP1000 key
(SKP1000 compatible with Chinese and English. Here is the Chinese version CI600 Plus tutorial. They are the same)
Firstly connect the main cable to the machine, then plug the OBDII adapter to the car.
Power on the SKP-1000 tablet machine, until you see the LOGO, press [YES]
Choose model: Hyundai, press "Confirm†to enter.
Choose "Smart cardâ€, press "Yes†to enter.
Choose †by car modelâ€, press "Yes†to enter.
Choose "SONATA 8 (with card slot), press "Yes†to enter.
Choose "Smart card (with card slot), press "Yes†to enter.
Follow the tip to turn off ignition, press "Yesâ€
Follow the tip to open the door and close for one time, press "Yesâ€.
Choose smart card to match, press "Yesâ€
Follow the tip, insert the smart card into the slot, and you can hear alarm sound, turn off the ignition, press "Yesâ€.
Input the password
Check if the password is correct, press "Yes†to confirm.
The first smart card program successfully, and it will ask you if you program the next one, press "Yes†to confirm.
Insert the second smart card into the slot, you can hear the alarm sound, press "Yesâ€.
SKP1000 Program Hyundai SONATA 8 key successfully, press "No†to back.
With two new smart card keys, you could start the car, if you need to add more keys, just repeat the above steps.
Done.
Posted by: OBDexpress.co.uk at
06:23 AM
| No Comments
| Add Comment
Post contains 259 words, total size 7 kb.
How to useLonsdorSKP1000 key programmerto program smart key on Hyundai SONATA 8.
(SKP1000 compatible with Chinese and English. Here is the Chinese version CI600 Plus tutorial. They are the same)
Firstly connect the main cable to the machine, then plug the OBDII adapter to the car.
Power on the SKP-1000 tablet machine, until you see the LOGO, press [YES] tomainmenu, Choose "Immobilizerâ€, press "Confirm†to vehicle list.
Choose model: Hyundai, press "Confirm†to enter.
Choose "Smart cardâ€, press "Yes†to enter.
Choose †by car modelâ€, press "Yes†to enter.
Choose "SONATA 8 (with card slot), press "Yes†to enter.
Choose "Smart card (with card slot), press "Yes†to enter.
Follow the tip to turn off ignition, press "Yesâ€
Follow the tip to open the door and close for one time, press "Yesâ€.
Choose smart card to match, press "Yesâ€
Follow the tip, insert the smart card into the slot, and you can hear alarm sound, turn off the ignition, press "Yesâ€.
Input the password
Check if the password is correct, press "Yes†to confirm.
The first smart card program successfully, and it will ask you if you program the next one, press "Yes†to confirm.
Insert the second smart card into the slot, you can hear the alarm sound, press "Yesâ€.
SKP1000 Program Hyundai SONATA 8 key successfully, press "No†to back.
With two new smart card keys, you could start the car, if you need to add more keys, just repeat the above steps.
Done.
Posted by: OBDexpress.co.uk at
06:23 AM
| No Comments
| Add Comment
Post contains 258 words, total size 7 kb.
July 29, 2017
VVDI PROG manual: how to read write chips with reflash cables:
1.MC9S12 Reflash Cable V1working with VVDI Prog
Function: Read & Write MC9S08, MC9S12 series chips, current version is
V1
Usage: Solder the line on pin of chips before reading& writing chips
Notes:
(1) Please check all connection lines,ensure correct and reliable
connection
(2) Please Don’t lengthen CLK and GND-C line, maybe lead to read datafailure
2.ECU Reflash Cableworking with VVDI Prog:
Function: Read & Write engine ECU
Usage: Solder the line on pin of chips before reading& writing chips
Notes:
Please check all connection lines, ensure correct and reliable connection
VVDI PROG ECU List:
MFRS TYPE SUPPORT REMARK
BMW E SERIES
MEVD17(N55) ï’
MEVD1724(N20) ï’
MEVD1726(N55) ï’
MEVD1729(N20) ï’
BMW F SERIES
MEVD172(N55) ï’
MEVD1724(N20) ï’
MEVD1725(N13) ï’
MEVD1726(N55) ï’
MEVD1728(N63/S63) ï’
MEVD1729(N20) ï’
MEVD172G(N55) ï’
MEVD172P(N20) ï’
MEVD172S(N55) ï’
BOMBARDIER QUADROCYCLE(2011) ï’
CHANGAN BENBEN MT20UED ï’
DELPHI
ME20U2-XET256 ï’
ME20U2-XET512 ï’
MT20U2-MC912DT128P ï’
MT20U2-2L33V ï’
MT20UED ï’
MT22-XEP768 ï’
MT60-XEP768 ï’
MT60(TC1766) ï’
MT80(TC1766) ï’
KIA ME17.9.11.1(TC1762) ï’
MAGNETI
MARELLI
IAW-6LP2.03 ï’
IAW-6LPA.01 ï’
RENAULT MODUS-XC164CS-32F ï’
VOLKSWAGEN
EDC17_CP14(TC1796) ï’
ME7.5.20(ST10F275) ï’
MED17.1(TC1766) ï’
VVDI PROG User Manual
MED17.5(TC1766) ï’
MED17.5.20(TC1766) ï’
OTHER XP8000E-XET256 ï’
BOSCH ME7.9.7.1 ï’
3.MCU Reflash CableV3 working with VVDI Prog:
Function: Read & Write MC68HC(9)12, V850, H8X, R5C series chips,
current version is V3
Usage: Solder the line on pin of chips before reading& writing chips
Notes:
(1) Please check all connection lines,ensure correct and reliable
connection
(2) Please Don’t lengthen CLK and GND-C line, maybe lead to read data failure
MFRS TYPE SUPPORT REMARK
RENESAS
V850
D70F3231 ï’
D70F3232 ï’
D70F3233 ï’
D70F3234 ï’
D70F3235 ï’
D70F3236 ï’
D70F3237 ï’
D70F3238 ï’
D70F3239 ï’
D70F3333 ï’
D70F3334 ï’
D70F3335 ï’
D70F3336 ï’
D70F3340 ï’
D70F3341 ï’
D70F3342 ï’
D70F3343 ï’
D70F3344 ï’
D70F3345 ï’
D70F3346 ï’
D70F3347 ï’
D70F3348 ï’
D70F3350 ï’
D70F3351 ï’
D70F3352 ï’
D70F3353 ï’
D70F3354 ï’
D70F3355 ï’
D70F3356 ï’
D70F3357 ï’
D70F3358 ï’
D70F3364 ï’
D70F3365 ï’
D70F3366 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
RENESAS
V850
D70F3367 ï’
D70F3368 ï’
D70F3370A ï’
D70F3371 ï’
D70F3372 ï’
D70F3373 ï’
D70F3374 ï’
D70F3375 ï’
D70F3376A ï’
D70F3377A ï’
D70F3378 ï’
D70F3379 ï’
D70F3380 ï’
D70F3381 ï’
D70F3382 ï’
D70F3383 ï’
D70F3384 ï’
D70F3385 ï’
D70F3402 ï’
D70F3403 ï’
D70F3403A ï’
D70F3416 ï’
D70F3417 ï’
D70F3421 ï’
D70F3422 ï’
D70F3423 ï’
D70F3424 ï’
D70F3425 ï’
D70F3426 ï’
D70F3427 ï’
D70F3433 ï’
D70F3451 ï’
D70F3452 ï’
D70F3453 ï’
D70F3454 ï’
D70F3464 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
RENESAS
V850
D70F3465 ï’
D70F3466 ï’
D70F3469 ï’
D70F3470 ï’
D70F3471 ï’
D70F3472 ï’
D70F3522 ï’
D70F3523 ï’
D70F3524 ï’
D70F3525 ï’
D70F3526 ï’
D70F3529 ï’
D70F3532 ï’
D70F3535 ï’
D70F3536 ï’
D70F3537 ï’
D70F3610 ï’
D70F3611 ï’
D70F3612 ï’
D70F3613 ï’
D70F3614 ï’
D70F3615 ï’
D70F3616 ï’
D70F3617 ï’
D70F3618 ï’
D70F3619 ï’
D70F3620 ï’
D70F3621 ï’
D70F3622 ï’
D70F3624 ï’
D70F3628 ï’
D70F3634 ï’
D70F3700 ï’
D70F3701 ï’
D70F3702 ï’
D70F3703 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
RENESAS
V850
D70F3704 ï’
D70F3706 ï’
D70F3707 ï’
D70F3709 ï’
D70F3710 ï’
D70F3711 ï’
D70F3712 ï’
D70F3715 ï’
D70F3716 ï’
D70F3717 ï’
D70F3718 ï’
D70F3719 ï’
D70F3720 ï’
D70F3721 ï’
D70F3722 ï’
D70F3723 ï’
D70F3724 ï’
D70F3739 ï’
D70F3740 ï’
D70F3741 ï’
D70F3742 ï’
D70F3743 ï’
D70F3744 ï’
D70F3745 ï’
D70F3746 ï’
D70F3778 ï’
D70F3779 ï’
D70F3780 ï’
D70F3781 ï’
D70F3782 ï’
D70F3783 ï’
D70F3784 ï’
D70F3785 ï’
D70F3786 ï’
D70F3826 ï’
D70F3827 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
RENESAS
V850
D70F3828 ï’
D70F3829 ï’
D70F3834 ï’
D70F3835 ï’
D70F3836 ï’
D70F3837 ï’
D70F4177 ï’
D70F4178 ï’
D70F4179 ï’
D70F4180 ï’
D70F3474A ï’
D70F3475A ï’
D70F3476A ï’
D70F3477A ï’
D70F3478A ï’
D70F3479A ï’
D70F3931B ï’
D70F3932B ï’
D70F3933B ï’
D70F3934B ï’
D70F3935B ï’
D70F3936B ï’
D70F3937B ï’
D70F3938B ï’
D70F3939B ï’
D70F3480A ï’
D70F3481A ï’
D70F3482A ï’
D70F3486A ï’
D70F3487A ï’
D70F3488A ï’
D70F3925A ï’
D70F3926A ï’
D70F3927A ï’
D70F3625 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
RENESAS
V850
D70F3529 ï’
D70F3548 ï’
D70F3549 ï’
D70F3550 ï’
D70F3551 ï’
D70F3552 ï’
D70F3553 ï’
D70F3554 ï’
D70F3555 ï’
D70F3556 ï’
D70F3557 ï’
D70F3558 ï’
D70F3559 ï’
D70F3560 ï’
D70F3561 ï’
D70F3564 ï’
D70F3570 ï’
D70F3571 ï’
D70F3572 ï’
D70F3573 ï’
D70F3574 ï’
D70F3575 ï’
D70F3576 ï’
D70F3577 ï’
D70F3578 ï’
D70F3579 ï’
D70F3580 ï’
D70F3582 ï’
D70F3583 ï’
D70F3584 ï’
D70F3585 ï’
D70F3592 ï’
D70F4000 ï’
D70F4001 ï’
D70F4002 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
RENESAS
V850
D70F4003 ï’
D70F4004 ï’
D70F4005 ï’
D70F4006 ï’
D70F4007 ï’
D70F4008 ï’
D70F4009 ï’
D70F4010 ï’
D70F4011 ï’
D70F4012 ï’
D70F3623 ï’
D70F3626 ï’
D70F3627 ï’
D70F3629 ï’
D70F3630 ï’
D70F3631 ï’
D70F3632 ï’
D70F3633 ï’
D70F3634 ï’
D70F3635 ï’
D70F3636 ï’
D70F3637 ï’
D70F3638 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
RENESAS
H8X
R5F61723 ï’
R5F61725 ï’
R5F61797 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
RENESAS
R8C
R5F21546E ï’
R5F21547E ï’
R5F21548E ï’
R5F2154AE ï’
R5F2154CE ï’
R5F21546F ï’
R5F21547F ï’
R5F21548F ï’
R5F2154AF ï’
R5F2154CF ï’
R5F21546G ï’
R5F21547G ï’
R5F21548G ï’
R5F2154AG ï’
R5F2154CG ï’
R5F21546H ï’
R5F21547H ï’
R5F21548H ï’
R5F2154AH ï’
R5F2154CH ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
MOTOROLA
MC68HC(9)08
MC68HC08AB16A_EEP ï’
MC68HC08ASxx_EEP ï’Support R&W secured chip
MC68HC08ASxxA_EEP ï’Support R&W secured chip
MC68HC08AZxx_EEP ï’Support R&W secured chip
MC68HC08AZxxA_EEP ï’Support R&W secured chip
MC68HC908ABxx_EEP ï’Support R&W secured chip
MC68HC908ASxx_EEP ï’Support R&W secured chip
MC68HC908ASxxA_EEP ï’Support R&W secured chip
MC68HC908ASxxA_FLASH ï’Support R&W secured chip
MC68HC908AZxx_EEP ï’Support R&W secured chip
MC68HC908AZxxA_EEP ï’Support R&W secured chip
MC68HC908AZxxA_FLASH ï’Support R&W secured chip
MC68HC908AZxxE_EEP ï’Support R&W secured chip
MC68HC908AZxxE_FLASH ï’Support R&W secured chip
MC68HC908GRxx ï’Support R&W secured chip
MC68HC908GTxx ï’Support R&W secured chip
MC68HC908GZxx ï’Support R&W secured chip
MC68HC908LJxx ï’Support R&W secured chip
MC68HC908LKxx ï’Support R&W secured chip
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
MOTOROLA
MC68HC(9)12
MC68HC12BC32 ï’
MC68HC12BE32 ï’
MC68HC912B32 ï’
MC68HC912BC32 ï’
MC68HC912BD32 ï’Support R&W secured chip
MC912D60A ï’Support R&W secured chip
MC912DG128 ï’Support R&W secured chip
MC912DG128A ï’Support R&W secured chip
MC912DT128 ï’Support R&W secured chip
MC912DT128A ï’Support R&W secured chip
MC912DT128P ï’Support R&W secured chip
Notes: ï’Already Support, ï‚£Support Soon
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
MOTOROLA
MC9S08
MC9S08AC ï’
MC9S08AW ï’
MC9S08DN ï’
MC9S08DV ï’
MC9S08DZ ï’
MC9S08EL ï’
MC9S08FL ï’
MC9S08GB ï’
MC9S08GW ï’
MC9S08GT ï’
MC9S08JE ï’
MC9S08JM ï’
MC9S08JS ï’
MC9S08LC ï’
MC9S08LG ï’
MC9S08LH ï’
MC9S08LL ï’
MC9S08MM ï’
MC9S08MP ï’
MC9S08QA ï’
MC9S08QB ï’
MC9S08QD ï’
MC9S08QE ï’
MC9S08QG ï’
MC9S08RC ï’
MC9S08RD ï’
MC9S08RE ï’
MC9S08RG ï’
MC9S08SC ï’
MC9S08SE ï’
MC9S08SF ï’
MC9S08SG ï’
MC9S08SH ï’
MC9S08SL ï’
MC9S08SU ï’
MC9S08SV ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
MOTOROLA
MC9S12
MC9S12A ï’Support R&W secured chip
MC9S12B ï’Support R&W secured chip
MC9S12C ï’Support R&W secured chip
MC9S12D ï’Support R&W secured chip
MC9S12DB ï’Support R&W secured chip
MC9S12DG ï’Support R&W secured chip
MC9S12DJ ï’Support R&W secured chip
MC9S12DP ï’Support R&W secured chip
MC9S12DT ï’Support R&W secured chip
MC9S12G ï’Support R&W secured chip
MC9S12GA ï’Support R&W secured chip
MC9S12GC ï’Support R&W secured chip
MC9S12GN ï’Support R&W secured chip
MC9S12HA ï’
MC9S12HY ï’
MC9S12HZ ï’Support R&W secured chip (3L16Y)
MC9S12KG ï’Support R&W secured chip (2L33V)
MC9S12KT ï’Support R&W secured chip (2L33V)
MC9S12P ï’
MC9S12XA ï’Support R&W secured chip
MC9S12XB ï’Support R&W secured chip
MC9S12XD ï’Support R&W secured chip
MC9S12XDP ï’Support R&W secured chip
MC9S12XDQ ï’Support R&W secured chip
MC9S12XDT ï’Support R&W secured chip
MC9S12XEA ï’Support R&W secured chip,auto detect data size
MC9S12XEG ï’Support R&W secured chip,auto detect data size
MC9S12XEP ï’Support R&W secured chip,auto detect data size
MC9S12XEQ ï’Support R&W secured chip,auto detect data size
MC9S12XET ï’Support R&W secured chip,auto detect data size
MC9S12XHY ï’
MC9S12XHZ ï’Support R&W secured chip
MC9S12XS ï’
MC9S12XF ï’Support R&W secured chip,auto detect data size
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
NXP
PCF79XX
PCF7922 ï’Need PCF79XX adapter
PCF7941 ï’Need PCF79XX adapter
PCF7945 ï’Need PCF79XX adapter
PCF7952 ï’Need PCF79XX adapter
PCF7953 ï’Need PCF79XX adapter
PCF7961 ï’Need PCF79XX adapter
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
ST
ST10F
ST10F269 ï’
ST10F272 ï’
ST10F275 ï’
ST10F276 ï’
ST10F280 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
INFINEON
XC2XXX
XC2060M ï’
XC2060N ï’
XC2336A ï’
XC2336B ï’
XC2361A ï’
XC2363A ï’
XC2364A ï’
XC2365A ï’
XC2361B ï’
XC2363B ï’
XC2364B ï’
XC2365B ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
ATMEL
ATMEGA
XXXX
ATMEGA48xx ï’48/48P/48PB
ATMEGA8 ï’
ATMEGA88xx ï’88/88P/88PB
ATMEGA16xx ï’16/162/164/164P/168(P/PB)/169(P)
ATMEGA32xx ï’
32/323/324(P/PB)/325(P)/3250(P)/
328(P/PB)/329(P/PB)/3290(P)
ATMEGA64xx ï’64/644(P)/645(P)/6450(P)/649(P)/6490(P)
ATMEGA103 ï’
ATMEGA128x ï’128/1280/1281
ATMEGA256x ï’2560/2561
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
INFINEON
XC164CS
XC164CS-16F ï’
XC164CS-32F ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
MICROCHIP
PIC18F
PIC18F6520 ï’
PIC18F6620 ï’
PIC18F6720 ï’
PIC18F8520 ï’
PIC18F8620 ï’
PIC18F8720 ï’
MICROCHIP
PIC12F
PIC12F635 ï’
PIC12F683 ï’
MICROCHIP
PIC16F
PIC16F631 ï’
PIC16F636 ï’
PIC16F639 ï’
PIC16F677 ï’
PIC16F684 ï’
PIC16F685 ï’
PIC16F687 ï’
PIC16F688 ï’
PIC16F689 ï’
PIC16F690 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
FUJITSU
MB91F
MB91F037 ï’
MB91F061 ï’
MB91F062 ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
INFINEON
TRICORE
TC1762-CAN ï’R&W via CAN
TC1766-CAN ï’R&W via CAN
TC1796-CAN ï’R&W via CAN
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
ST
STM8
STM8AF5xxx ï’
STM8AF6xxx ï’
STM8AL31xx ï’
STM8AL3Lxx ï’
STM8L051xx ï’
STM8L052xx ï’
STM8L101xx ï’
STM8L151xx ï’
STM8L152xx ï’
STM8L162xx ï’
STM8S003xx ï’
STM8S007xx ï’
STM8S103xx ï’
STM8S105xx ï’
STM8S207xx ï’
STM8S208xx ï’
STM8S903xx ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
MOTOROLA
MPC560X
MPC560XB ï’
MPC560XC ï’
MPC560XD ï’
MPC560XE ï’
MPC560XP ï’
MPC560XS ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
ST
SPC560X
SPC560XS ï’
SPC560BXX ï’
SPC560CXX ï’
SPC560DXX ï’
SPC560PXX ï’
SPC56APXX ï’
VVDI PROG User Manual
MFRS TYPE SUPPORT REMARK
ST
ST7
ST72(F)321XX ï’
ST72(F)521XX ï’
SOURCE:http://blog.obdexpress.co.uk/2017/07/27/vvdi-prog-readwrite-chips-with-ecumcumc9s12-reflash-cables/
Posted by: OBDexpress.co.uk at
02:48 AM
| No Comments
| Add Comment
Post contains 1635 words, total size 244 kb.
July 28, 2017
Free download
Rheingold 3.55.11 Standalone ISTA-P 3.58.3.003 torrent(being tested)
ISTA-D 3.54.12 ISTA-P 3.58.0.500 Software(tested, cracked)
BMW software is offered here to free download, to work with INPA cable or BMW ICOM A2 for BMW diagnosis and programming.
Standalone versions of ISTA-D and ISTA-P.
SQLiteDBs 3.55.14, including EN, DE, RU, OTHER.
Workable device:
For unpack archives use 7-zip 15.12 or Winrar 5.30 and higher ( unblock archives if needed ).
Install:
Ediabas, Java, vcredist 2010 x86 x64, vcredist 2013 x86 x64, vs90_piaredist, net framework 4.5.2 or higher.
Rheingold :
Unpack, forexamlein D:\Rheingold, unpack and copy SQLiteDBs in Rheingold\SQLiteDBs\, run RCleanerV4.3.exe from Tools folder.
Apply ISTA-D Reg Fix for your system (x86 or x64) from Tools folder.
Run D:\Rheingold\TesterGUI\bin\Release\ISTAGUI.exe.
If ask license, enter it from License.txt file. Enter 1 in ISIS field, ignore error and press ok.
ISTA-P :
Install Networktool.exe, for K-DCAN cable. (ICOM doesn’t need it).
Unpack in the root of any drive, forexampleD:\ISTA-P.
Run BMW ISTA-P Loader V4.9.exe from Tools folder.
Choose language, resolution and expert mode options. Ignoremessageabout resolution.
This postsourcefromCar OBD2 Tools global one-stop shopping supplier ---OBDexress.co.uk Official technical blog :http://blog.obdexpress.co.uk/2017/07/28/rheingold-3-55-11-ista-p-3-58-3-003-torrent-free-download/
Posted by: OBDexpress.co.uk at
02:41 AM
| No Comments
| Add Comment
Post contains 196 words, total size 11 kb.
July 26, 2017
2017 MPPS cable: MPPS software 21.0.1.3hardware 1.09.03
Mpps v21 in uk:
http://www.obdexpress.co.uk/wholesale/mpps-v18-main-tricore-multiboot-breakout-tricore-cable.html
Mpps v21 price: €85
Mpps v21 software download:
http://blog.obdexpress.co.uk/2017/01/19/mpps-v21-obd-tricore-boot-download-car-list-review/
Mpps v21 windows 7: confirmed!
Mpps v21 reviews:
http://blog.obdexpress.co.uk/2017/07/10/mpps-v21-good-or-not/
Posted by: OBDexpress.co.uk at
06:36 AM
| No Comments
| Add Comment
Post contains 41 words, total size 5 kb.
July 25, 2017
There are five Chinese versions ofRenault CAN CLIP 169 diagnostic tool, which best? The yellow PCB version or the green version?
Renault CAN CLIPchinaclone: what confirmed:
Renault clip v169 Windows 7:Confirmed
OBDII diagnostics:Confirmed
Reprogramming:Confirmed
!!!!!!!Renault CAN CLIP programming can be done only withYELLOW PCBversion (SP19-E). GREEN versions failed!
Best-quality:Renault CAN CLIP diagnostic tool with item no. SP19-A
Hottest:Renault CLIP diagnostic interface with item no. SP19-B
Cheapest:Renault CAN CLIP diagnostic interface with item no. SP19-D
High-quality:Renault CAN CLIP diagnostic interface with item no. SP19-C
Read the following tips if you decide to buy items from China.
Tip 1: Quality & Price
In China, you can get anything – at/for any price, problem is that you will have to accept the quality. "You get what you pay for†– And this is more or less true, there will be always someone somewhere "trying to†do it for less, but there are thresholds and once you step under them, you will have to suffer from the results.Qualityof a product also depends on the material you purchase (You can’t simply make gold out of wood)
Tip 2: Reasons for low costs
The only reason why theobdiidiagnostic cablesare made in China isbecause90% of the materials (micro- controllersand ICs) come from there. That is, it’s mainly aboutcost, most people would not be ready to pay 3-4 times the price just for the device being made in Europe or the US.
So, items are produced inhigh quantity and cost savinghere
Source:http://blog.obdexpress.co.uk/2017/07/25/renault-can-clip-169-yellow-pcb-vs-green-pcb/
Posted by: OBDexpress.co.uk at
03:10 AM
| No Comments
| Add Comment
Post contains 267 words, total size 29 kb.
July 24, 2017
From what I can see, there are currently 3 different Chinese PCB versions ofGallettov54!
– There is one, where there are 2ledson the top of
OBDEXPRESS.CO.UK, sells two different versions of Galletto v54, from different manufacturers:
(note: on the site, the pictures for both items are the same, but
–Item No. SE61-Gis the other version they sell, it comes in a brown box, has a power adapter for bench work, and has a green led, next to the power connector,
http://www.obdexpress.co.uk/wholesale/fgtech-
–Item No. SE61-
This is the version I have, and I have successfully tested it in several cars:
Audi A4 2.0tdi2008edc17cp14:
have the one with red LED next to power jack. Igavetested
Tricore 2010audia6: read OK
2005 Skodaoctaviavrs: K line OK
GP read 1_3 MJT 75 hp:Twenty-six seconds to read. File 2 MB
BMW X6 3.0D 2008EDC16: OBD read and write WORK
Citroen C3 Bosch EDC
5 minutes total to write.
BMW 525
BMW edc16c35: failed
http://www.autoobdtool.fr/
Posted by: OBDexpress.co.uk at
02:13 AM
| No Comments
| Add Comment
Post contains 300 words, total size 22 kb.
July 21, 2017
Recently, one customer with KESS 5.017 Ksuite 2.23 @obdexpress.co.uk has tested and confirmed to work on Windows 10 as well. See the feedback from him,
†MyKESS V5.017cantwork onWIN7system,
But
So, KESS V2 5.017 Windows 10 worked!
Posted by: OBDexpress.co.uk at
02:32 AM
| No Comments
| Add Comment
Post contains 96 words, total size 10 kb.
July 20, 2017
Kess V2 5.017 manual: how to setup/install Kess V2 5.017 Ksuite 2.23 on Windows 7or Windows 8 or XP system.
Kess V2 5.017 Windows
Kess V2 5.017 Windows 7…..Worked!
Kess V2 5.017 Windows 8…..Worked!
How to install Kess V2 5.017 on Windows 7/8/XP:
Here, take windows
Kess V2 5.017 software installation steps:
(Kess V2 5.017 used with Ksuite 2.23)
First, disconnect all network connection!
Open KSuite 2.23 (E
and run "ksuite_222_v2†exe.
To complete the setup, click
Accept a Microsoft Visual C++ 2005 License Terms
Installation language: Here: "U.S Englishâ€.
Click "Next†until "Finish†to complete Ksuite 2.22 setup wizard.
And choose "Englishâ€.
On desktop, openâ€K-Suite Propertiesâ€
Replace all files in C:/Ksuite 2.23 with E:/Ksuite 2.23
Found New Hardware Wizard: click on "Next†then "Finishâ€.
Setup USB Device: "My Computerâ€, thenâ€Manageâ€, thenâ€Device Managerâ€
Open K-Suite and now it’s Ksuite 2.23 software!
Click "Info†button and check the firmware version is 5.017.
So, Kess v2 5.017 now is ready for use!!!
Kess v2 5.017tested on2007 Toyota Vitz (P9x): WORKED!
Kess v2
- it’s
workingwith original database on Win7 Win8 (not only XP)
2. Fully activated: all protocols available: EDC17 / k-line / DSG / DQ200 DQ250 DQ500 Gearbox / ST10 …., no gray buttons!!!! - 3. can work with the 2016 model;
-
i compared it withkess 4.03:kess 5.017 adds 140+ vehicle types; can support car/truck/tractor/bikes (version 4.036 supports cars only)
It’s nice when it works.
Posted by: OBDexpress.co.uk at
07:01 AM
| No Comments
| Add Comment
Post contains 262 words, total size 51 kb.
July 18, 2017
It’s used to update/flash ECUs,writeECMmodified andprogramProbeholder/Dimsport aids.
The frame can work with ECM Chip Tuning Tools such asKESS,KTAG,FGTECH,BDM 100,KTM100,CMD, DIMSPORT AIDS...
This set includes: aluminum alloy support pair, acrylic sheet (LED lamp andinterface),BDMprobes 4, wire 4
How to use theBDM framealuminium:
Insert the probe to connect the BOOT on the ECU board and CNF1, the legend for the public MED17.5.2 computer board.
Applicable to open the ECU, to avoid welding jumper. In the acrylic board with LED light bar, help the case of poor light to see the hole of the board.
Jumper for the plug-in, to reduce the trouble of welding the connection, easy to connect, and can be more than a series.
LED power situation, the whole board can see clearly. LED power supply with ECU equipment with12V power supply, connect the probe, you can disconnect the power supply, to the equipment for the
The new LED light bar interface is fixed on the acrylic plate, for the straight type.
Add a LED light to facilitate the case of poor light to see the computer board, the picture on the LED lights may be updated at any time, only for more practical.
The tip of the probe is specially designed and scalable.
How does the BDM frame work with ECU programmers:
Here, how to work withKtag 7.020:
Posted by: OBDexpress.co.uk at
06:34 AM
| No Comments
| Add Comment
Post contains 245 words, total size 16 kb.
It’s used to update/flash ECUs,
The frame can work with ECM Chip Tuning Tools such asKESS,KTAG,FGTECH,BDM 100,KTM100,CMD, DIMSPORT AIDS...
This set includes: aluminum alloy support pair, acrylic sheet (LED lamp
How to use
Insert the probe to connect the BOOT on the ECU board and CNF1, the legend for the public MED17.5.2 computer board.
Applicable to open the ECU, to avoid welding jumper. In the acrylic board with LED light bar, help the case of poor light to see the hole of the board.
Jumper for the plug-in, to reduce the trouble of welding the connection, easy to connect, and can be more than a series.
LED power situation, the whole board can see clearly. LED power supply with ECU equipment with12V power supply, connect the probe, you can disconnect the power supply, to the equipment for the
The new LED light bar interface is fixed on the acrylic plate, for the straight type.
Add a LED light to facilitate the case of poor light to see the computer board, the picture on the LED lights may be updated at any time, only for more practical.
The tip of the probe is specially designed and scalable.
How does the BDM frame work with ECU programmers:
Here, how to work
Posted by: OBDexpress.co.uk at
06:34 AM
| No Comments
| Add Comment
Post contains 248 words, total size 18 kb.
July 17, 2017
http://www.obdexpress.co.uk/wholesale/mpps-v18-main-tricore-multiboot-breakout-tricore-cable.html
MPPSV18 download:
http://www.obdexpress.co.uk/wholesale/mpps-v18-main-tricore-multiboot-breakout-tricore-cable.html
MPPSV16 download:
http://www.obdexpress.co.uk/wholesale/newest-mpps-ecu-chip-tuning-edc15-edc16-edc17-checksum.html
MPPS V21 car list:
http://www.obdexpress.co.uk/upload/pro/mpps-v21-car-list.csv
MPPS V18 car list:
http://www.obdexpress.co.uk/upload/pro/mpps-v18-vehicle-list-free-download.pdf
MPPS V16 car list:
http://www.obdexpress.co.uk/upload/pro/mpps-v16-ecu-chip-tuning-supported-car-model-list.pdf
What’s NEW inMPPSV21car list:
-OBD:
*Volvo ME7 CAN R/W/
Bench only at the moment.
*Volvo EDC15C11 CAN R/W/
Bench only at the moment.
*Bentley ME7.1.1 CAN R/W/
*Master/Slave ECUs.
*VAG ALL TDI Bosch EDC17 X UDS drive now supports *EDC17C46 and EDC17C64 ECUs.
Must be unlocked first using
*Generic Tricore VAG Only Multi ECU –MPPSContainer file flasher.
*Can be used to flash firmware updates and OBD UNLOCK files created using new VAS FRF file utility
-Tricore Boot
*Added new file checksum utility
(M)EDC Flash checksum
(M)EDCEepromchecksum
Simos PCR
Simos 8
Simos SID305
Added new VAS FRF file special function utility
CreateMPPScontainer file from FRF file.
Can be used to perform software updates
Create OBD UNLOCKMPPScontainer file from FRF file.
Can be used to perform OBD unlock
Create READ UNLOCKMPPScontainer file from FRF file.
Can be used to perform full read unlock
Create BIN file from FRF file.
Can be used when ECU can not be read from OBD.
What’s NEW inMPPSV18car list:
- Tricore Boot
This module adds boot mode support for controllers with
Features:
Auto detects ECU and processor type. No need to select from
Read/Write of all
Patch function for OBD Flashing of TPROT ECU’s (supports only VAG at the moment)
TPROT / DS check feature, for testing if TPROT is active without opening ECU.
Supports BoschuptoTP12
Supports Siemens (current only for ECU’s without password protection),
Support for unlocking of VAG Simos PCR and Simos 8
Checksum Correction supported for Bosch MEDC17
- MultiBoot
This module adds support for advanced functions on Marelli ECU’s.
Features:
Read / Write of
Fiat 6F3 – Full Read / WriteMicro, Flash
Fiat 6JF – Full Read / Write Micro
Fiat 8DF – Full Read / Write Micro and
Fiat 8F2 – Full Read / Write Micro
Fiat 8F3 – Full Read / Write Micro
Fiat 8GM – Full Read / Write Micro
Fiat 8GS – Full Read / Write Micro
Fiat 5SF3 – Full Read / Write Flash
Fiat 5SF3 – Full Read / WriteEEpromover K-Line.
Fiat 5SF8 – Full Read / Write Flash
Fiat 5SF9 – Full Read / Write Flash
Fiat ME7.9.10 – Full Read / Write Micro over CAN.
Fiat ME7.6.3 – Full Read / Write Micro over CAN.
Opel 6O2 – Full Read / WriteMicro, Flash
Opel 6O3 – Full Read / WriteMicro, Flash
Opel 6JO – Full Read / Write Micro
What’s NEW inMPPSV16car list:
1) EDC15 improvements
2) DDE4 improvements
3) VAG EDC17 CHECKSUM !!!!!
4) Improvement of many protocols (many bugs have been removed)
5) New cars have been added
2017 NewestMPPSSoftware Car List:
(use "Ctrl+F" to search quickly
)
Make Model Engine EcuMake EcuType Connection Read Write Auto Checksum
Alfa Romeo 145 1.4 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 145 1.6 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 145 1.8 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 145 2.0 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 145 1.9 JTD Bosch EDC15C5 K-Line Yes Yes Checksum Button
Alfa Romeo 146 1.4 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 146 1.6 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 146 1.8 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 146 2.0 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 146 1.9 JTD Bosch EDC15C5 K-Line Yes Yes Checksum Button
Alfa Romeo 147 1.6 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo 147 1.8 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo 147 2.0 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo 147 3.2 24v Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo 147 1.9 JTD Bosch EDC15C7 K-Line Yes Yes Checksum Button
Alfa Romeo 147 1.9 JTD 8V Bosch EDC16C8 K-Line Yes Yes Yes
Alfa Romeo 147 1.9 JTD 16V Bosch EDC16C9 K-Line Yes Yes Yes
Alfa Romeo 156 1.6 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 156 1.8 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 156 2.0 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 156 1.6 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo 156 1.8 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo 156 2.0 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo 156 3.2 24v Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo 156 1.9 JTD Bosch EDC15C7 K-Line Yes Yes Checksum Button
Alfa Romeo 156 2.4 JTD Bosch EDC15C7 K-Line Yes Yes Checksum Button
Alfa Romeo 156 1.9 JTD 16V Bosch EDC16C8 K-Line Yes Yes Yes
Alfa Romeo 156 2.4 JTD 20V Bosch EDC16C8 K-Line Yes Yes Yes
Alfa Romeo 156 2.5 V6 Bosch ME2.1 K-Line No Yes Checksum Button
Alfa Romeo 156 2.5 V6 Bosch ME3.1 K-Line Yes Yes Yes
Alfa Romeo 159 1.9 JTD 8V Bosch EDC16C8 K-Line Yes Yes Yes
Alfa Romeo 159 1.9 JTD 16V Bosch EDC16C9 K-Line Yes Yes Yes
Alfa Romeo 159 2.2 JTS 16V Bosch MED7.6.1 KLine No Yes Yes
Alfa Romeo 159 2.4 JTD 20V Bosch EDC16C9 K-Line Yes Yes Yes
Alfa Romeo 166 2.0 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo 166 2.0 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo 166 2.4 JTD Bosch EDC15C7 K-Line No Yes Yes
Alfa Romeo 166 2.4 JTD 20V Bosch EDC16C8 K-Line Yes Yes Yes
Alfa Romeo 166 2.5 V6 Bosch ME2.1 K-Line No Yes Checksum Button
Alfa Romeo 166 3.0 V6 Bosch ME2.1 K-Line No Yes Checksum Button
Alfa Romeo 166 2.5 V6 Bosch ME3.1 K-Line Yes Yes Yes
Alfa Romeo 166 3.0 V6 Bosch ME3.1 K-Line Yes Yes Yes
Alfa Romeo 166 3.2 V6 Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo Brera 1.9 JTD 16V Bosch EDC16C9 K-Line Yes Yes Yes
Alfa Romeo Brera 2.2 JTS 16V Bosch MED7.6.1 KLine No Yes Yes
Alfa Romeo Brera 2.4 JTD 20V Bosch EDC16C39 K-Line Yes Yes Yes
Alfa Romeo Crosswagon Q4 1.9 JTD Bosch EDC15C7 K-Line Yes Yes Checksum Button
Alfa Romeo Crosswagon Q4 1.9 JTD 16V Bosch EDC16C39 K-Line Yes Yes Yes
Alfa Romeo Gulietta 1.4 MultiAir Marelli MJD8GA CAN Yes Yes Yes
Alfa Romeo Gulietta 1.4 16v Bosch ME7.9.10 CAN No Yes Yes
Alfa Romeo Gulietta 1.4 16v T Bosch ME7.9.10 CAN No Yes Yes
Alfa Romeo Gulietta 1.6 JTDM 16v Bosch EDC16C39-5.5 CAN Yes Yes Yes
Alfa Romeo Gulietta 2.0 JTDM 16v Bosch EDC16C39-5.5 CAN Yes Yes Yes
Alfa Romeo GT 3.2 24v Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo GT 1.9 JTD 16V Bosch EDC16C8 K-Line Yes Yes Yes
Alfa Romeo GTV 1.8 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo GTV 2.0 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo GTV 3.0 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo GTV 2.0 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo GTV 3.2 V6 Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo GTV 3.0 V6 24V Bosch ME3.1 K-Line Yes Yes Yes
Alfa Romeo GTV 3.0 V6 Bosch ME2.1 K-Line No Yes Checksum Button
Alfa Romeo Mito 1.3 JTDM Marelli Multijet 6SF CAN Yes Yes Yes
Alfa Romeo Mito 1.4 16v Bosch ME7.9.10 CAN No Yes Yes
Alfa Romeo Mito 1.4 16v T Bosch ME7.9.10 CAN No Yes Yes
Alfa Romeo Mito 1.4 16v Bosch ME7.9.10 KLine No Yes Yes
Alfa Romeo Mito 1.4 16v T Bosch ME7.9.10 KLine No Yes Yes
Alfa Romeo Mito 1.6 JTDM 16v Bosch EDC16C39-5.5 CAN Yes Yes Yes
Alfa Romeo Mito 1.4 MultiAir Marelli MJD8GA CAN Yes Yes Yes
Alfa Romeo Mito 1.3 JTDM Marelli MJD8F2/3 CAN Yes Yes Yes
Alfa Romeo Spider 1.8 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo Spider 1.8 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo Spider 2.0 TS Bosch M1.5.5 K-Line No Yes Yes
Alfa Romeo Spider 2.0 TS Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo Spider 3.2 V6 Bosch ME7.3.1 K-Line Yes Yes Yes
Alfa Romeo Spider 3.0 V6 24V Bosch ME3.1 K-Line Yes Yes Yes
Alfa Romeo Sportwagon 2.0 TS Bosch ME7.3.1 K-Line Yes Yes Checksum Button
Alfa Romeo Sportwagon 1.9 JTD Bosch EDC15C7 K-Line Yes Yes Checksum Button
Alfa Romeo Sportwagon 1.9 JTD 16V Bosch EDC16C8 K-Line Yes Yes Yes
Audi A1 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Audi A2 1.2 TDI_34 Bosch EDC15 K-Line Yes Yes Checksum Button
Audi A2 1.4 TDI_PD Bosch EDC15 K-Line Yes Yes Checksum Button
Audi A3 1.4 TSI Bosch MED17.5.5 CAN Yes Yes Yes
Audi A3 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Audi A3 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Audi A3 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Audi A3 1.9 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Audi A3 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Audi A3 2.0 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Audi A3 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Audi A3 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Audi A3 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi A3 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi A3 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi A3 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Audi A3 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Audi A3 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Audi A3 1.8 NA Bosch M5.92 K-Line No Yes Checksum Button
Audi A3 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Audi A3 3.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi A3 3.2L Bosch ME7.1.1 CAN Yes Yes Yes
Audi A3 ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Audi A3 ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Audi A3 ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Audi A3 ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Audi A4 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Audi A4 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Audi A4 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Audi A4 1.9 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Audi A4 1.9 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Audi A4 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Audi A4 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Audi A4 2.0 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Audi A4 2.7 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Audi A4 3.0 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Audi A4 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Audi A4 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi A4 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi A4 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi A4 2.0L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi A4 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Audi A4 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Audi A4 2.4L Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi A4 2.8L 30v Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi A4 3.0L V6 Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi A4 1.8L Bosch M5.92 K-Line No Yes Checksum Button
Audi A4 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Audi A4 2.4L Bosch M5.92 K-Line No Yes Checksum Button
Audi A4 2.8L Bosch M5.92 K-Line No Yes Checksum Button
Audi A4 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Audi A4 ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Audi A4 ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Audi A4 ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Audi A4 ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Audi A5 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Audi A5 2.7 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Audi A5 3.0 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Audi A5 4.2 FSI Bosch MED9.1 CAN Yes Yes Yes
Audi A5 ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Audi A5 ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Audi A5 ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Audi A5 ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Audi A6 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Audi A6 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Audi A6 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Audi A6 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Audi A6 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Audi A6 2.0 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Audi A6 2.7 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Audi A6 3.0 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Audi A6 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi A6 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi A6 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi A6 2.0L Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi A6 2.0L Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi A6 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Audi A6 2.4L Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi A6 2.7L Turbo Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi A6 2.7L Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi A6 3.0L V6 Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi A6 3.2 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Audi A6 4.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi A6 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Audi A6 2.0L Bosch M5.92 K-Line No Yes Checksum Button
Audi A6 2.4L Bosch M5.92 K-Line No Yes Checksum Button
Audi A6 2.8L Bosch M5.92 K-Line No Yes Checksum Button
Audi A6 ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Audi A6 ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Audi A6 ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Audi A6 ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Audi A7 ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Audi A7 ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Audi A7 ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Audi A7 ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Audi A7 3.2 FSI Siemens Simos 8.2 UDS Yes Yes Yes
Audi A7 3.0 TFSI Siemens Simos 8.4 UDS Yes Yes Yes
Audi A7 3.0 TFSI Siemens Simos 8.5 UDS Yes Yes Yes
Audi A8 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Audi A8 3.0 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Audi A8 4.0 TDI Bosch EDC16C4 K-Line ECU 1 Yes Yes Yes
Audi A8 4.0 TDI Bosch EDC16C4 K-Line ECU 2 Yes Yes Yes
Audi A8 4.2 TDI Bosch EDC16C34 K-Line/CAN ECU 1 Yes Yes Yes
Audi A8 4.2 TDI Bosch EDC16C34 K-Line/CAN ECU 2 Yes Yes Yes
Audi A8 3.2 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Audi A8 3.7L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi A8 4.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi A8 4.2L Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi A8 4.2L Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi A8 5.2L V10 FSI Bosch MED9.1.2 CAN ECU 1 Yes Yes Yes
Audi A8 5.2L V10 FSI Bosch MED9.1.2 CAN ECU 2 Yes Yes Yes
Audi A8 4.2L Bosch M5.92 K-Line No Yes Checksum Button
Audi A8 ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Audi A8 ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Audi A8 ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Audi A8 ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Audi AllRoad 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Audi AllRoad 2.7L Turbo Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi AllRoad 2.7L Turbo Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi AllRoad 4.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi AllRoad 2.7 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Audi Q3 ALL TDI Bosch EDC17CP14 CAN Yes Yes Yes
Audi Q3 ALL TDI Bosch EDC17CP04 UDS Yes Yes Yes
Audi Q3 ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Audi Q3 ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Audi Q5 ALL TDI Bosch EDC17CP14 CAN Yes Yes Yes
Audi Q5 ALL TDI Bosch EDC17CP04 UDS Yes Yes Yes
Audi Q5 ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Audi Q5 ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Audi Q7 3.0 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Audi Q7 3.0 V6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Audi Q7 3.2 V6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Audi Q7 4.2 TDI Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Audi Q7 4.2 TDI Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Audi Q7 ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Audi Q7 ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Audi Q7 ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Audi Q7 ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Audi R8 4.2L V8 FSI Bosch MED9.1 CAN ECU 1 Yes Yes Yes
Audi R8 4.2L V8 FSI Bosch MED9.1 CAN ECU 2 Yes Yes Yes
Audi R8 5.2L V10 FSI Bosch MED9.1 CAN ECU 1 Yes Yes Yes
Audi R8 5.2L V10 FSI Bosch MED9.1 CAN ECU 2 Yes Yes Yes
Audi RS4 2.7 Turbo Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi RS4 2.7 Turbo Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi RS4 4.2L V8 FSI Bosch MED9.1 CAN ECU 1 Yes Yes Yes
Audi RS4 4.2L V8 FSI Bosch MED9.1 CAN ECU 2 Yes Yes Yes
Audi RS6 4.2T Quattro Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi RS6 5.0L V10 TFSI Bosch MED9.1.2 CAN ECU 1 Yes Yes Yes
Audi RS6 5.0L V10 TFSI Bosch MED9.1.2 CAN ECU 2 Yes Yes Yes
Audi S3 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi S3 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Audi S4 2.7 Turbo Bosch ME7.1 K-Line Yes Yes Checksum Button
Audi S4 4.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi S4 4.2L V8 FSI Bosch MED9.1.2 CAN ECU 1 Yes Yes Yes
Audi S4 4.2L V8 FSI Bosch MED9.1.2 CAN ECU 2 Yes Yes Yes
Audi S5 4.2L V8 FSI Bosch MED9.1 CAN ECU 1 Yes Yes Checksum Button
Audi S5 4.2L V8 FSI Bosch MED9.1.3 CAN ECU 1 Yes Yes Yes
Audi S5 4.2L V8 FSI Bosch MED9.1.3 CAN ECU 2 Yes Yes Yes
Audi S6 4.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi S6 5.2L V10 FSI Bosch MED9.1 CAN ECU 1 Yes Yes Yes
Audi S6 5.2L V10 FSI Bosch MED9.1 CAN ECU 2 Yes Yes Yes
Audi S8 4.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi S8 5.2L V10 FSI Bosch MED9.1.2 CAN ECU 1 Yes Yes Yes
Audi S8 5.2L V10 FSI Bosch MED9.1.2 CAN ECU 2 Yes Yes Yes
Audi TT 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Audi TT 3.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Audi TT 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Bentley Arnage T 6800cc V8 Twin Turbo Bosch ME7.1.1 Master Ecu K-Line Yes Yes Checksum Button
Bentley Arnage T 6800cc V8 Twin Turbo Bosch ME7.1.1 Slave Ecu K-Line Yes Yes Checksum Button
Bentley Arnage T 6800cc V8 Twin Turbo Bosch ME7.1.1 Master Ecu CAN Yes Yes Yes
Bentley Arnage T 6800cc V8 Twin Turbo Bosch ME7.1.1 Slave Ecu CAN Yes Yes Yes
Bentley Continental Flying Spur 6000cc W12 Twin Turbo Bosch ME7.1.1 Master Ecu K-Line Yes Yes Checksum Button
Bentley Continental Flying Spur 6000cc W12 Twin Turbo Bosch ME7.1.1 Slave Ecu K-Line Yes Yes Checksum Button
Bentley Continental Flying Spur 6000cc W12 Twin Turbo Bosch ME7.1.1 Master Ecu CAN Yes Yes Yes
Bentley Continental Flying Spur 6000cc W12 Twin Turbo Bosch ME7.1.1 Slave Ecu CAN Yes Yes Yes
Bentley Continental GT 6000cc W12 Twin Turbo Bosch ME7.1.1 Master Ecu K-Line Yes Yes Checksum Button
Bentley Continental GT 6000cc W12 Twin Turbo Bosch ME7.1.1 Slave Ecu K-Line Yes Yes Checksum Button
Bentley Continental GT 6000cc W12 Twin Turbo Bosch ME7.1.1 Master Ecu CAN Yes Yes Yes
Bentley Continental GT 6000cc W12 Twin Turbo Bosch ME7.1.1 Slave Ecu CAN Yes Yes Yes
Bentley Continental GTC 6000cc W12 Twin Turbo Bosch ME7.1.1 Master Ecu K-Line Yes Yes Checksum Button
Bentley Continental GTC 6000cc W12 Twin Turbo Bosch ME7.1.1 Slave Ecu K-Line Yes Yes Checksum Button
Bentley Continental GTC 6000cc W12 Twin Turbo Bosch ME7.1.1 Master Ecu CAN Yes Yes Yes
Bentley Continental GTC 6000cc W12 Twin Turbo Bosch ME7.1.1 Slave Ecu CAN Yes Yes Yes
Bmw Series 1 118 1.8D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 1 118 1.8D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 1 120 2.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 1 120 2.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 3 1.9L Bosch M5.2 K-Line No No Checksum Button
Bmw Series 3 1.9L Bosch M5.2.1 K-Line No No Checksum Button
Bmw Series 3 2.0L Siemens MS41 K-Line No No Checksum Button
Bmw Series 3 2.0L Siemens MS42 K-Line No No Checksum Button
Bmw Series 3 2.0L Siemens MS43 K-Line No No Checksum Button
Bmw Series 3 2.3L Siemens MS41 K-Line No No Checksum Button
Bmw Series 3 2.3L Siemens MS42 K-Line No No Checksum Button
Bmw Series 3 2.5L Siemens MS41 K-Line No No Checksum Button
Bmw Series 3 2.5L Siemens MS42 K-Line No No Checksum Button
Bmw Series 3 2.5L Siemens MS43 K-Line No No Checksum Button
Bmw Series 3 2.8L Siemens MS41 K-Line No No Checksum Button
Bmw Series 3 2.8L Siemens MS42 K-Line No No Checksum Button
Bmw Series 3 3.0L Siemens MS43 K-Line No No Checksum Button
Bmw Series 3 3.2 Evo Siemens MSS50 K-Line No No Checksum Button
Bmw Series 3 3.2 E46 Siemens MSS54 K-Line No No Checksum Button
Bmw Series 3 318 1.8D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 3 318 1.8D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 3 320 2.0D Bosch DDE3.0 K-Line No No Checksum Button
Bmw Series 3 320 2.0D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series 3 320 2.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 3 320 2.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 3 325 2.5D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 3 325 2.5D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 3 330 3.0D Bosch DDE4.0 K-Line Yes Yes Yes
Bmw Series 3 330 2.0D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series 3 330 3.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 3 330 3.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 3 335 3.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 3 325 3.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 5 2.0L Siemens MS41 K-Line No No Checksum Button
Bmw Series 5 2.0L Siemens MS42 K-Line No No Checksum Button
Bmw Series 5 2.0L Siemens MS42 K-Line No No Checksum Button
Bmw Series 5 2.3L Siemens MS41 K-Line No No Checksum Button
Bmw Series 5 2.2L Siemens MS42 K-Line No No Checksum Button
Bmw Series 5 2.3L Siemens MS42 K-Line No No Checksum Button
Bmw Series 5 2.5L Siemens MS41 K-Line No No Checksum Button
Bmw Series 5 2.5L Siemens MS43 K-Line No No Checksum Button
Bmw Series 5 2.8L Siemens MS41 K-Line No No Checksum Button
Bmw Series 5 2.8L Siemens MS42 K-Line No No Checksum Button
Bmw Series 5 3.0L Siemens MS43 K-Line No No Checksum Button
Bmw Series 5 3.8L V8 Bosch M5.2 K-Line No No Checksum Button
Bmw Series 5 3.8L V8 Bosch M5.2.1 K-Line No No Checksum Button
Bmw Series 5 4.0-4.4 V8 Bosch M5.2 K-Line No No Checksum Button
Bmw Series 5 4.0-4.4 V8 Bosch M5.2.1 K-Line No No Checksum Button
Bmw Series 5 5.0L V8 M5 Siemens MSS52 K-Line No No Checksum Button
Bmw Series 5 2.0D Bosch DDE3.0 K-Line No No Checksum Button
Bmw Series 5 520 2.0D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series 5 520 2.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 5 320 2.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 5 525 2.5D Bosch DDE4.0 K-Line Yes Yes Yes
Bmw Series 5 525 2.5D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series 5 525 2.5D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 5 520 2.5D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 5 530 3.0D Bosch DDE4.0 K-Line Yes Yes Yes
Bmw Series 5 530 3.0D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series 5 530 3.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 5 530 3.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 5 535 3.0D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series 5 535 3.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 5 535 3.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 5 4.4-4.6L V8 Bosch ME7.2 K-Line Yes Yes Checksum Button
Bmw Series 6 3.0L Siemens MSS52 K-Line No No Checksum Button
Bmw Series 6 4.4L Siemens MSS52 K-Line No No Checksum Button
Bmw Series 6 635 3.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 6 635 3.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 7 2.8L Siemens MS41 K-Line No No Checksum Button
Bmw Series 7 2.8L Siemens MS42 K-Line No No Checksum Button
Bmw Series 7 3.8L V8 Bosch M5.2 K-Line No No Checksum Button
Bmw Series 7 3.8L V8 Bosch M5.2.1 K-Line No No Checksum Button
Bmw Series 7 4.0-4.4 V8 Bosch M5.2 K-Line No No Checksum Button
Bmw Series 7 4.0-4.4 V8 Bosch M5.2.1 K-Line No No Checksum Button
Bmw Series 7 730 3.0D Bosch DDE4.0 K-Line Yes Yes Yes
Bmw Series 7 730 3.0D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series 7 730 3.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series 7 730 3.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series 7 4.4-4.6L V8 Bosch ME7.2 K-Line Yes Yes Checksum Button
Bmw Series X3 2.0D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series X3 2.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series X3 2.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series X5 3.0L Siemens MS43 K-Line No No Checksum Button
Bmw Series X5 3.0D Bosch DDE4.0 K-Line Yes Yes Yes
Bmw Series X5 4.4L-4.6L Bosch ME7.2 K-Line Yes Yes Checksum Button
Bmw Series X5 3.0D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series X5 3.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series X5 3.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series X6 3.0D Bosch EDC16C31 K-Line_Slow Yes Yes Yes
Bmw Series X6 3.0D Bosch EDC16C35 K-Line_Slow/CAN Yes Yes Yes
Bmw Series X6 3.0D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Bmw Series Z Z3 1.9L Bosch M5.2 K-Line No No Checksum Button
Bmw Series Z Z3 1.9L Bosch M5.2.1 K-Line No No Checksum Button
Bmw Series Z Z3 2.0-2.8 Siemens MS41 K-Line No No Checksum Button
Bmw Series Z Z3 2.0-2.8 Siemens MS42 K-Line No No Checksum Button
Bmw Series Z Z3 2.2L Siemens MS43 K-Line No No Checksum Button
Bmw Series Z Z3 3.0L Siemens MS43 K-Line No No Checksum Button
Bmw Series Z Z3 3.2 Evo Siemens MSS50 K-Line No No Checksum Button
Bmw Series Z Z3 3.2 E46 Siemens MSS54 K-Line No No Checksum Button
Bmw Series Z Z8 5.0L V8 Siemens MSS54 K-Line No No Checksum Button
Chevrolet Captiva 1.9 16V TD MJ Bosch EDC16C39 CAN Yes Yes Yes
Chevrolet Captiva 2.0 16V VCDI Bosch EDC16C39 CAN Yes Yes Yes
Chevrolet Cruiz 2.0 16V VCDI Bosch EDC16C39 CAN Yes Yes Yes
Chrysler 300C 3.0 CRD Bosch EDC16CP31-8 K-Line/CAN Yes Yes Yes
Chrysler PT Cruiser 2.2L CRD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Chrysler PT Cruiser 2.2L CRD Bosch EDC16C2-9 K-Line/CAN Yes Yes Yes
Chrysler Sebring 2.0 CRD Bosch EDC16U31 CAN Yes Yes Yes
Chrysler Voyager 2.5L CRD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Chrysler Voyager 2.8L CRD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Chrysler Voyager 2.8L CRD Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Citroen Berlingo 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Citroen Berlingo 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Citroen C2 1.6L Bosch MP7.4.4 K-Line Yes Yes Checksum Button
Citroen C2 1.4 HDI Siemens SID 804 K-Line Yes Yes Yes
Citroen C3 1.4 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Citroen C3 1.4 16v HDI Delphi DDCR K-Line Yes Yes Checksum Button
Citroen C3 1.6 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Citroen C3 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Citroen C3 1.6L Bosch MP7.4.4 K-Line Yes Yes Checksum Button
Citroen C3 1.4 HDI Siemens SID 804 K-Line Yes Yes Yes
Citroen C4 1.6 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Citroen C4 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Citroen C4 1.6L Bosch MP7.4.4 K-Line Yes Yes Checksum Button
Citroen C4 2.0 TD Siemens SID803A K-Line/CAN Yes Yes Yes
Citroen C5 2.0L 16v Marelli 6LPA K-Line Yes Yes Checksum Button
Citroen C5 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Citroen C5 2.2 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Citroen C5 2.0 HDI Siemens SID 804 K-Line Yes Yes Yes
Citroen C5 2.0 HDI Delphi DCM 3.5 CAN Yes Yes Yes
Citroen C5 2.0 TD Siemens SID803A K-Line/CAN Yes Yes Yes
Citroen C6 2.0L 16v Marelli 6LPA K-Line Yes Yes Checksum Button
Citroen C8 2.0L 16v Marelli 6LPA K-Line Yes Yes Checksum Button
Citroen C8 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Citroen DS4 2.0 HDI Delphi DCM 3.5 CAN Yes Yes Yes
Citroen DS5 2.0 HDI Delphi DCM 3.5 CAN Yes Yes Yes
Citroen Evasion 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Citroen Jumper 2.0 HDI Bosch EDC15C K-Line Yes Yes Checksum Button
Citroen Jumper 2.2 HDI Bosch EDC15C K-Line Yes Yes Checksum Button
Citroen Jumper 2.8 HDI Bosch EDC15C K-Line Yes Yes Checksum Button
Citroen Jumpy 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Citroen Jumpy 2.0 TD Siemens SID803A K-Line/CAN Yes Yes Yes
Citroen Picasso 1.6 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Citroen Picasso 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Citroen Picasso 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Citroen Picasso 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Citroen Saxo 1.6 VTR Bosch MP7.4.4 K-Line Yes Yes Checksum Button
Citroen Saxo 1.4 HDI Siemens SID 804 K-Line Yes Yes Yes
Citroen Xantia 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Citroen Xantia 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Citroen Xsara 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Citroen Xsara 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Dodge Avenger 2.0 16V CRD Bosch EDC16U31 CAN Yes Yes Yes
Dodge Caliber 2.0 16V CRD Bosch EDC16U31 CAN Yes Yes Yes
Dodge Journey 2.0 16V CRD Bosch EDC16U31 CAN Yes Yes Yes
Ducati Hypermotard 1100 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Hypermotard 1100 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster 1100 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster 1100 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster 400 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster 620 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster 620 Dark Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster 695 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster S2R Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster S2R 1000 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster S2R 800 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster S2R Dark Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster S4R Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster S4R TS Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Monster S4R S TS Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Multistrada 1100 DS Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Multistrada 1100 S DS Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Multistrada 1100 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Multistrada 1100 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Multistrada 620 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Multistrada 620 Dark Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sportclassic GT 1100 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sportclassic Smart 1100 LE Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sportclassic Sport 1100 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sportclassic Sport 1100 B Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sportclassic Sport 1100 M Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sportclassic Sport 1100 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sportclassic Sport 1100 T Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sporttouring ST3 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sporttouring ST3 S ABS Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sporttouring ST4 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Sporttouring ST4 S ABS Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Streetfighter 1100 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Streetfighter 1100 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 1098 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 1098 R Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 1098 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 1198 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 1198 R Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 1198 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 749 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 749 Dark Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 749 R Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 749 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 848 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 848 Dark Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 999 Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 999 R Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Superbike 999 S Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Supersport 1100 DS Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ducati Supersport 1100 S DS Marelli 59M/5AM K-Line Yes Yes Checksum Button
Ferrari 360 Modena 360 Modena Bosch ME7.3H4 K-Line Yes Yes Checksum Button
Fiat 500 0.9 JTM Marelli TwinAir MJD8GSF CAN Yes Yes Yes
Fiat 500 0.9 JTM Marelli TwinAir MJD8GSW CAN Yes Yes Yes
Fiat 500 1.2L Marelli 5SF3.M1/M2 CAN Yes Yes Yes
Fiat 500 1.2L Marelli 5SF8/9 CAN Yes Yes Yes
Fiat 500 1.2 16V Marelli IAW MM9 CAN Yes Yes Yes
Fiat 500 1.3 JTDM Marelli Multijet 6F3 CAN Yes Yes Yes
Fiat 500 1.3 JTDM Marelli Multijet MJD8DF CAN Yes Yes Yes
Fiat 500 1.3 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Fiat 500 1.4T Bosch ME7.9.10 CAN No Yes Yes
Fiat 600 1.1 E3 Marelli IAW 59F K-Line No No Yes
Fiat Brava 1.2 12V Bosch M1.5.5 K-Line No No Yes
Fiat Brava 1.6 16V Marelli IAW 49F K-Line No No Yes
Fiat Brava 1.6 16V Marelli IAW 4EF K-Line No No Yes
Fiat Brava 1.9 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Bravo 1.2 12V Bosch M1.5.5 K-Line No No Yes
Fiat Bravo 1.4 16v Bosch ME7.9.10 CAN No Yes Yes
Fiat Bravo 1.4 16v T Bosch ME7.9.10 CAN No Yes Yes
Fiat Bravo 1.4 16v Bosch ME7.9.10 KLine No Yes Yes
Fiat Bravo 1.4 16v T Bosch ME7.9.10 KLine No Yes Yes
Fiat Bravo 1.6 16V Marelli IAW 49F K-Line No No Yes
Fiat Bravo 1.6 16V Marelli IAW 4EF K-Line No No Yes
Fiat Bravo 1.6 JTDM 16v Bosch EDC16C39-5.5 CAN Yes Yes Yes
Fiat Bravo 1.9 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Bravo 1.9 JTD 16V Bosch EDC16C9 K-Line Yes Yes Yes
Fiat Bravo 2.0 24V Bosch ME3.1 K-Line Yes Yes Yes
Fiat Bravo 2.0 JTDM 16v Bosch EDC16C39-5.5 CAN Yes Yes Yes
Fiat Bravo 2.4 JTD 20V Bosch EDC16C9 K-Line Yes Yes Yes
Fiat Croma 1.9 JTDM Bosch EDC16C9 K-Line Yes Yes Yes
Fiat Croma 2.4 JTDM Bosch EDC16C9 K-Line Yes Yes Yes
Fiat Coupe 2.0 24V Bosch ME3.1 K-Line Yes Yes Yes
Fiat Coupe 2.0 24V Bosch ME3.1 K-Line Yes Yes Yes
Fiat Coupe 1.2 16V Bosch ME7.H4 K-Line Yes Yes Yes
Fiat Coupe 1.3 JDTM Marelli Multijet 6JF K-Line Yes Yes Yes
Fiat Coupe 1.3 JDTM Marelli Multijet 6F3 K-Line Yes Yes Yes
Fiat Coupe 1.3 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Fiat Coupe 1.3 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Fiat Coupe 1.6 JTDM 16v Bosch EDC16C39-5.5 CAN Yes Yes Yes
Fiat Coupe 1.9 JTDM Bosch EDC16C9 K-Line Yes Yes Yes
Fiat Coupe 1.9 JTD Bosch EDC15C7-2.13 K-Line Yes Yes Checksum Button
Fiat Ducato 1.9 JTDM Bosch EDC16C9 K-Line Yes Yes Yes
Fiat Ducato 2.0 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Ducato 2.0 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Fiat Ducato 2.0 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Fiat Ducato 2.2 JTD MJ Bosch EDC16C39 K-Line Yes Yes Yes
Fiat Ducato 2.3 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Ducato 2.3 JTD MJ Bosch EDC16C39 K-Line Yes Yes Yes
Fiat Ducato 2.3 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Fiat Ducato 2.4 JTDM Bosch EDC16C9 K-Line Yes Yes Yes
Fiat Ducato 2.8 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Ducato 3.0 JTD MJ Bosch EDC16C39 K-Line Yes Yes Yes
Fiat Fiorino 1.3 JDTM Marelli Multijet 6JF K-Line Yes Yes Yes
Fiat Fiorino 1.3 JDTM Marelli Multijet 6F3 K-Line Yes Yes Yes
Fiat Fiorino 1.3 JDTM Marelli Multijet 6F3 CAN Yes Yes Yes
Fiat Fiorino 1.3 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Fiat Fiorino 1.9 JTDM Bosch EDC16C9 K-Line Yes Yes Yes
Fiat Grande Punto 0.9 JTM Marelli TwinAir MJD8GSF CAN Yes Yes Yes
Fiat Grande Punto 0.9 JTM Marelli TwinAir MJD8GSW CAN Yes Yes Yes
Fiat Grande Punto 1.2L Marelli 5SF3.M1/M2 CAN Yes Yes Yes
Fiat Grande Punto 1.2L Marelli 5SF8/9 CAN Yes Yes Yes
Fiat Grande Punto 1.3 JTDM Marelli Multijet 6F3 CAN Yes Yes Yes
Fiat Grande Punto 1.3 JDTM Marelli Multijet 6F3 K-Line Yes Yes Yes
Fiat Grande Punto 1.3 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Fiat Grande Punto 1.4 Bosch ME7.6.3 CAN No Yes Yes
Fiat Grande Punto 1.4 Bosch ME7.6.3 KLine No Yes Yes
Fiat Grande Punto 1.4T Bosch ME7.9.10 CAN No Yes Yes
Fiat Grande Punto 1.4 16v Bosch ME7.9.10 KLine No Yes Yes
Fiat Grande Punto 1.4 16v T Bosch ME7.9.10 KLine No Yes Yes
Fiat Grande Punto 1.9 JTD MJ Bosch EDC16C39 CAN Yes Yes Yes
Fiat Idea 1.2 16V Bosch ME7.H4 K-Line Yes Yes Checksum Button
Fiat Idea 1.2 16V Marelli IAW 5SF3 K-Line Yes Yes Yes
Fiat Idea 1.2 16V Marelli IAW 5SF8 K-Line Yes Yes Yes
Fiat Idea 1.3 JDTM Marelli Multijet 6JF K-Line Yes Yes Yes
Fiat Idea 1.3 JDTM Marelli Multijet 6F3 K-Line Yes Yes Yes
Fiat Idea 1.3 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Fiat Idea 1.3 JTDM Marelli Multijet MJD8DF K-Line Yes Yes Yes
Fiat Idea 1.9 JTDM Bosch EDC16C9 K-Line Yes Yes Yes
Fiat Marea 1.9 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Marea 2.0 24V Bosch ME3.1 K-Line Yes Yes Checksum Button
Fiat Marea 2.4 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Multipla 1.6 16V Marelli IAW 5NF K-Line No No Yes
Fiat Multipla 1.9 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Multipla 1.9 JTDM Bosch EDC16C K-Line Yes Yes Yes
Fiat Panda 1.2 8V Marelli IAW 59F K-Line No No Yes
Fiat Panda 1.2 16V Marelli IAW 5NF K-Line No No Yes
Fiat Panda 1.2 16V Marelli IAW 5SF3 K-Line Yes Yes Yes
Fiat Panda 1.2 16V Marelli IAW 5SF8 K-Line Yes Yes Yes
Fiat Panda 1.2 16V Marelli IAW MM9 CAN Yes Yes Yes
Fiat Panda 1.3 JDTM Marelli Multijet 6JF K-Line Yes Yes Yes
Fiat Panda 1.3 JDTM Marelli Multijet 6F3 K-Line Yes Yes Yes
Fiat Panda 1.3 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Fiat Panda 1.3 JTDM Marelli Multijet MJD8DF K-Line Yes Yes Yes
Fiat Punto 1.2 8V Marelli IAW 59F K-Line No No Yes
Fiat Punto 1.2 16V Bosch ME7.H4 K-Line Yes Yes Yes
Fiat Punto 1.2 16V Marelli IAW 5SF3 K-Line Yes Yes Yes
Fiat Punto 1.3 JDTM Marelli Multijet 6JF K-Line Yes Yes Yes
Fiat Punto 1.3 JDTM Marelli Multijet 6F3 K-Line Yes Yes Yes
Fiat Punto 1.3 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Fiat Punto 1.3 JTDM Marelli Multijet MJD8DF K-Line Yes Yes Yes
Fiat Punto 1.9 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Punto 1.9 JTDM Bosch EDC16C K-Line Yes Yes Yes
Fiat Qubo 1.3 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Fiat Qubo 1.3 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Fiat Qubo 1.3 JTDM Marelli Multijet MJD8DF K-Line Yes Yes Yes
Fiat Seidici 1.3 JDTM Marelli Multijet 6F3 K-Line Yes Yes Yes
Fiat Seidici 1.3 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Fiat Seidici 1.3 JTDM Marelli Multijet MJD8DF K-Line Yes Yes Yes
Fiat Seidici 1.6 JTD MJ Bosch EDC16C39 K-Line Yes Yes Yes
Fiat Seidici 1.9 JTD MJ Bosch EDC16C39 K-Line Yes Yes Yes
Fiat Seidici 2.0 JTD MJ Bosch EDC16C39 K-Line Yes Yes Yes
Fiat Scudo 2.0 TD Bosch EDC5C2 K-Line Yes Yes Checksum Button
Fiat Scudo 2.0 TD Siemens SID803A K-Line/CAN Yes Yes Yes
Fiat Stilo 1.6 16V Marelli IAW 5NF K-Line No No Yes
Fiat Stilo 1.9 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Fiat Stilo 1.9 JTD Bosch EDC16C8 K-Line Yes Yes Yes
Fiat Stilo 1.9 JTD MJ Bosch EDC16C39 K-Line Yes Yes Yes
Fiat Stilo 1.9 JDTM Marelli Multijet K-Line Yes Yes Yes
Fiat Stilo 2.0 24V Bosch ME7.H4 K-Line Yes Yes Yes
Fiat Strada 1.3 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Fiat Strada 1.3 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Fiat Strada 1.3 JTDM Marelli Multijet MJD8DF K-Line Yes Yes Yes
Fiat Ulisse 2.0 TD Bosch EDC5C2 K-Line Yes Yes Checksum Button
Fiat Ulisse 2.2 TD Bosch EDC5C2 K-Line Yes Yes Checksum Button
Ford C-Max 1.6 TDCi Bosch EDC16C3 K-Line\CAN Yes Yes Yes
Ford C-Max 1.6 TDCi Bosch EDC16C34 K-Line\CAN Yes Yes Yes
Ford C-Max 1.6 TDCi Bosch EDC16C34-5 K-Line\CAN Yes Yes Yes
Ford C-Max 2.0 TDi Siemens Sid 803 CAN Yes Yes Yes
Ford C-Max 2.0 TDi Siemens Sid 803A-83M CAN Yes Yes Yes
Ford Fiesta 1.4 TDCi Siemens Sid 206 CAN Yes Yes Yes
Ford Fiesta 1.4 TDCi Siemens Sid 802/804 CAN Yes Yes Yes
Ford Fiesta 1.6 TDCi Bosch EDC16C3 K-Line\CAN Yes Yes Yes
Ford Fiesta 1.6 TDCi Bosch EDC16C34-2 K-Line\CAN Yes Yes Yes
Ford Fiesta 1.6 TDCi Bosch EDC16C34-5 K-Line\CAN Yes Yes Yes
Ford Focus 1.6 TDCi Bosch EDC16C3 K-Line\CAN Yes Yes Yes
Ford Focus 1.6 TDCi Bosch EDC16C34-2 K-Line\CAN Yes Yes Yes
Ford Focus 1.6 TDCi Bosch EDC16C34-5 K-Line\CAN Yes Yes Yes
Ford Focus ST 2.5 T Bosch ME9.0 CAN Yes Yes Yes
Ford Focus 2.0 TDi Siemens Sid 803 CAN Yes Yes Yes
Ford Focus 2.0 TDi Siemens Sid 803A-83M CAN Yes Yes Yes
Ford Fusion Style 1.4 TDCi Siemens Sid 206 CAN Yes Yes Yes
Ford Fusion Style 1.4 TDCi Siemens Sid 802/804 CAN Yes Yes Yes
Ford Fusion Style 1.6 TDCi Bosch EDC16C34-2 K-Line\CAN Yes Yes Yes
Ford Fusion Style 1.6 TDCi Bosch EDC16C34-5 K-Line\CAN Yes Yes Yes
Ford Galaxy 1.9 TDI Bosch EDC15C K-Line Yes Yes Checksum Button
Ford Galaxy 2.0 TDCi Siemens SID 206 CAN Yes Yes Yes
Ford Galaxy 2.2 TDCi Siemens SID 206 CAN Yes Yes Yes
Ford KA 1.3 TDCi Marelli Multijet 6F3 CAN Yes Yes Yes
Ford Kuga 2.0 TDCi Siemens SID 206 CAN Yes Yes Yes
Ford Kuga 2.0 TDCi Delphi DCM 3.5 CAN Yes Yes Yes
Ford Kuga 2.0 TDi Siemens Sid 803A-83M CAN Yes Yes Yes
Ford Mondeo 2.0 TDCi Siemens SID 206 CAN Yes Yes Yes
Ford Mondeo 2.0 TDCi Delphi DCM 3.5 CAN Yes Yes Yes
Ford S-Max 2.0 TDCi Siemens SID 206 CAN Yes Yes Yes
Ford S-Max 2.0 TDCi Delphi DCM 3.5 CAN Yes Yes Yes
Generic Micro Boot Generic Bosch ME2.1 256Kb Kline Yes Yes Checksum Button
Generic Micro Boot Generic Bosch ME2.8 512Kb Kline No No Checksum Button
Generic Micro Boot Generic Bosch ME7.XX 512Kb Kline No No Checksum Button
Generic Micro Boot Generic Bosch ME7.XX 1Mb Kline No No Checksum Button
Generic Micro Boot Generic Bosch EDC15CX Kline No No Checksum Button
Generic Micro Boot Generic Bosch EDC15P/EDC15V (VAG) Kline No No Checksum Button
Generic Micro Boot Generic Multi ST10F168 Kline Yes Yes Checksum Button
Generic Micro Boot Generic Multi ST10F269 Kline Yes Yes Checksum Button
Generic Micro Boot Generic Multi ST10F272 Kline Yes Yes Checksum Button
Generic Micro Boot Generic Multi ST10F280 Kline Yes Yes Checksum Button
Generic Micro Boot Generic Multi ST10F273 Kline No No Checksum Button
Generic Micro Boot Generic Multi ST10F275 Kline No No Checksum Button
Generic Micro Boot Generic Multi ST10F296 Kline No No Checksum Button
Generic Micro Boot Generic Bosch ST10F296 (1024Kb) Kline No No Checksum Button
Generic Micro Boot Generic Sagem S2000 (C167/ST10) Kline Yes Yes Checksum Button
Generic Micro Boot Generic Delphi DDCR (C167/ST10) Kline Yes Yes Checksum Button
Generic Micro Boot Generic Siemens EMS3132 C167 Kline Yes Yes Checksum Button
Generic Micro Boot Generic Siemens SID 801/801A C167/(ST10) Kline Yes Yes Checksum Button
Generic Micro Boot Generic Bosch ST10F296 (832Kb + 1024Kb) Kline No No Checksum Button
Generic Micro Boot Generic Siemens SIM4LE/SIM4SE (C167/ST10) Kline No No Checksum Button
Generic Micro Boot Generic Siemens DMEEMS2 (C167/ST10) Kline Yes Yes Checksum Button
Generic Micro Boot Generic Siemens SIM4LKE (C167/ST10) Kline Yes Yes Checksum Button
Generic Micro Boot Generic Siemens MS42/MS43 (C167/ST10) Kline Yes Yes Checksum Button
Generic EEprom VAG Bosch EDC15X E2p Kline Yes Yes Checksum Button
Generic EEprom VAG Bosch ME7X M95xxx E2p Kline Yes Yes Checksum Button
Generic EEprom VAG Bosch ME7X ST95P08 E2p Kline Yes Yes Checksum Button
Generic EEprom FIAT Bosch MED7.1.1 E2p Kline Yes Yes Checksum Button
Generic EEprom FIAT Bosch MED7.6.2 E2p Kline Yes Yes Checksum Button
Generic EEprom FIAT Bosch MED7.6.1 E2p Kline Yes Yes Checksum Button
Generic EEprom FIAT Bosch ME7.9.10 E2p Kline Yes Yes Checksum Button
Generic EEprom FIAT Bosch ME7.3.1 Hybrid E2p Kline Yes Yes Checksum Button
Generic EEprom FIAT Bosch ME3.1/ME7.3H4 Hybrid E2p Kline Yes Yes Checksum Button
Generic EEprom OPEL Bosch ME1.5.5 Hybrid E2p Kline Yes Yes Checksum Button
Generic EEprom OPEL Bosch ME7.6H4 Hybrid E2p Kline Yes Yes Checksum Button
Generic EEprom Peugeot/Citroen Siemens SID 801/801A E2p Kline Yes Yes Checksum Button
Generic EEprom Peugeot/Citroen Siemens SID 804 E2p Kline Yes Yes Checksum Button
Generic EEprom Peugeot/Citroen Siemens SID 801/801A E2p Kline Yes Yes Checksum Button
Generic EEprom MCC Smart Bosch MEG1.x E2p Kline Yes Yes Checksum Button
Generic EEprom MCC Smart Bosch MEG1.x E2p Kline Yes Yes Checksum Button
Generic EEprom Volvo Bosch ME7.0 CAN 250k/500k Yes Yes Checksum Button
Generic EEprom Volvo Bosch EDC15C11-4 CAN 250k Yes Yes Checksum Button
Generic Tricore VAG Only Bosch EDC17/MED17 Tricore CAN No No Checksum Button
Generic Tricore VAG Only Multi MPPS Container file UDS CAN No No Checksum Button
Holden Signum 2.2 SRI Delco GM PT K-Line No No Checksum Button
Holden Signum 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Holden Signum 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Holden Vectra 2.2 SRI Delco GM PT K-Line No No Checksum Button
Holden Vectra 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Holden Vectra 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Honda Accord 2.2 CDTi Bosch EDC16C7 K-Line Yes Yes Yes
Honda Civic 1.5 CDI Bosch EDC15C7 K-Line Yes Yes Checksum Button
Honda Civic 2.2 CDTi Bosch EDC16C2-4 K-Line Yes Yes Yes
Honda CR-v 2.2 CDTi Bosch EDC16C2-4.50 K-Line Yes Yes Yes
Hyundai Accent 1.5 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Hyundai Elantra 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Hyundai Getz 1.5 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Hyundai Getz 1.5 CRDI Bosch EDC16C39 K-Line Yes Yes Yes
Hyundai H1 Startex 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Hyundai i30 1.6 CDI Bosch EDC16C39 K-Line Yes Yes Yes
Hyundai Matrix 1.5 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Hyundai Santa Fe 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Hyundai Santa Fe 2.0 CDI Bosch EDC16C39 K-Line Yes Yes Yes
Hyundai Sonata 2.0 CDI Bosch EDC16C39 K-Line Yes Yes Yes
Hyundai Trajet 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Hyundai Tucson 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Hyundai Tucson 2.0 CRDI Bosch EDC16C39 K-Line Yes Yes Yes
Isuzu D-Max 3.0L DT Bosch EDC15M K-Line No No Checksum Button
Isuzu Rodeo 2.5L DT Bosch EDC15M K-Line No No Checksum Button
Iveco Daily 2.3 29 L 10 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.3 29 L 10 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.3 29 L 12 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.3 29 L 12 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.3 35 C 10 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.3 35 C 10 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.3 35 C 12 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.3 35 C 12 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.3 35 S 10 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.3 35 S 10 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.3 35 C 9 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.3 35 C 9 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.8 35 C 13 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.8 35 C 13 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.8 35 C 14 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.8 35 C 14 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.8 35 C 15 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.8 35 C 15 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.8 35 S 13 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.8 35 S 13 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.8 40 C 15 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.8 40 C 15 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 2.8 60 C 15 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 2.8 60 C 15 Bosch EDC16C39 K-Line Yes Yes Yes
Iveco Daily 3.0 35 C 17 Bosch EDC7 K-Line Yes Yes Yes
Iveco Daily 3.0 35 C 17 Bosch EDC16C39 K-Line Yes Yes Yes
Jaguar S-Type 2.7 TD V6 Siemens Sid 204 CAN Yes Yes Yes
Jaguar X-Type 2.7 TD V6 Siemens Sid 204 CAN Yes Yes Yes
Jeep Cherokee 2.5 CRD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Jeep Cherokee 2.8 16V CRD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Jeep Cherokee 2.8 16V CRD Bosch EDC16C2-C2 K-Line/CAN Yes Yes Yes
Jeep Cherokee 2.8 16V CRD Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Jeep Commander 3.0 CRD Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Jeep Compass 2.0 CRD Bosch EDC16U31 CAN Yes Yes Yes
Jeep Grand Cherokee 2.7 CRD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Jeep Grand Cherokee 3.0 CRD Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Jeep Liberty 2.5 CRD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Jeep Liberty 2.8 16V CRD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Jeep Liberty 2.8 16V CRD Bosch EDC16C2-C2 K-Line/CAN Yes Yes Yes
Jeep Liberty 2.8 16V CRD Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Jeep Patriot 2.0 CRD Bosch EDC16U31 CAN Yes Yes Yes
Jeep Wrangler 2.8 CRD Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Kia Carens 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Kia Carens 2.0 CRDI Bosch EDC16C39 K-Line Yes Yes Yes
Kia Ceed 1.6 CRDI Bosch EDC16C39 K-Line Yes Yes Yes
Kia Ceed 2.0 CRDI Bosch EDC16C39 K-Line Yes Yes Yes
Kia Rio 1.5 CRDI Bosch EDC16C39 K-Line Yes Yes Yes
Kia Sorento 2.5 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Kia Sorento 2.5 CRDI Bosch EDC16C39 K-Line Yes Yes Yes
Kia Sportage 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Kia Sportage 2.0 CRDI Bosch EDC16C39 K-Line Yes Yes Yes
KTM X Bow 2.0 TFSI Bosch MED9.1 Can Yes Yes Checksum Button
Lancia K 2.4 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Lancia Delta 1.4 16v Bosch ME7.9.10 KLine No Yes Yes
Lancia Delta 1.4 16v T Bosch ME7.9.10 KLine No Yes Yes
Lancia Delta 1.6 JTDM 16v Bosch EDC16C39-5.5 CAN Yes Yes Yes
Lancia Delta 2.0 JTDM 16v Bosch EDC16C39-5.5 CAN Yes Yes Yes
Lancia Lybra 2.0L Bosch ME7.3.1 K-Line Yes Yes Yes
Lancia Lybra 1.9 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Lancia Lybra 2.4 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Lancia Lybra 1.9 JTD Bosch EDC16C K-Line Yes Yes Yes
Lancia Lybra 2.4 JTD Bosch EDC16C K-Line Yes Yes Yes
Lancia Musa 1.2 16V Bosch ME7.H4 K-Line Yes Yes Yes
Lancia Musa 1.3 JTDM Marelli Multijet 6JF K-Line Yes Yes Yes
Lancia Musa 1.3 JDTM Marelli Multijet 6F3 K-Line Yes Yes Yes
Lancia Musa 1.3 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Lancia Musa 1.3 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Lancia Musa 1.3 JTDM Marelli Multijet MJD8DF K-Line Yes Yes Yes
Lancia Musa 1.9 JTDM Bosch EDC16C K-Line Yes Yes Yes
Lancia Phedra 2.0 TD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Lancia Phedra 2.2 TD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Lancia Phedra 2.2 TD Bosch EDC16CP39 K-Line/CAN Yes Yes Yes
Lancia Thesis 2.0 24V Bosch ME7.3.1 K-Line Yes Yes Yes
Lancia Thesis 2.4 JTD Bosch EDC15C K-Line Yes Yes Checksum Button
Lancia Thesis 2.4 JTD Bosch EDC16C K-Line Yes Yes Yes
Lancia Ypsilon 1.2 16V Bosch ME7.H4 K-Line Yes Yes Yes
Lancia Ypsilon 1.2 16V Marelli IAW 5SF3 K-Line Yes Yes Yes
Lancia Ypsilon 1.2 16V Marelli IAW 5SF8 K-Line Yes Yes Yes
Lancia Ypsilon 1.3 JTDM Marelli Multijet 6JF K-Line Yes Yes Yes
Lancia Ypsilon 1.3 JDTM Marelli Multijet 6F3 K-Line Yes Yes Yes
Lancia Ypsilon 1.3 JTDM Marelli Multijet MJD8F2/3 K-Line Yes Yes Yes
Lancia Ypsilon 1.3 JTDM Marelli Multijet MJD8F2/3 CAN Yes Yes Yes
Lancia Ypsilon 1.3 JTDM Marelli Multijet MJD8DF K-Line Yes Yes Yes
Lancia Zeta 2.0 TD Bosch EDC5C2 K-Line Yes Yes Checksum Button
Land Rover Defender 2.5 TD5 Lucas Mems3 K-Line Yes Yes Checksum Button
Land Rover Discovery 2.2 TD4 Bosch EDC16CP39 CAN Yes Yes Yes
Land Rover Discovery 2.5 TD5 Lucas Mems3 K-Line Yes Yes Checksum Button
Land Rover Discovery 2.7 TDV6 è½Siemens SID 201/203/204 CAN Yes Yes Yes
Land Rover Freelander 2.0 CDT Bosch DDE4.0 K-Line Yes Yes Yes
Land Rover Freelander 2.2 TD4 Bosch EDC16CP39 CAN Yes Yes Yes
Land Rover Range Rover 3.0 TD6 Bosch DDE4.0 K-Line Yes Yes Yes
Land Rover Range Rover 4.4-4.6L V8 Bosch ME7.2 K-Line Yes Yes Checksum Button
Land Rover Range Rover Sport 2.7 TDV6 è½Siemens SID 201/203/204 CAN Yes Yes Yes
Land Rover Range Rover Sport 3.6 TDV8 è½Siemens SID 201/203/204 CAN Yes Yes Yes
London Taxis International TX4 TX4 2.5 VM TDI Bosch EDC16C39 K-Line Yes Yes Yes
London Taxis International TX4 TX4 2.5 VM TDI Bosch EDC16C9 K-Line Yes Yes Yes
Mazda 3 Mazda 3 1.6 Tdi Bosch EDC16C3 K-Line\CAN Yes Yes Yes
Mazda 5 Mazda 5 2.0 MZR-CD 110hp Denso RF7K/RF8K CAN Yes Yes Yes
Mazda 5 Mazda 5 2.0 MZR-CD 143hp Denso RFAR/RFYG CAN Yes Yes Yes
Mazda 6 Mazda 6 2.0 MZR-CD 110hp Denso RF7K/RF8K CAN Yes Yes Yes
Mazda 6 Mazda 6 2.0 MZR-CD 110hp Denso RF8G CAN Yes Yes Yes
Mazda 6 Mazda 5 2.0 MZR-CD 143hp Denso RFAR/RFYG CAN Yes Yes Yes
Mazda 6 Mazda 6 2.2 MZR-CD 163hp Denso R2AB CAN Yes Yes Yes
Mazda 6 Mazda 6 2.2 MZR-CD 185hp Denso R2AB CAN Yes Yes Yes
Mazda 6 Mazda 6 2.2 MZR-CD 185hp Denso R2AB CAN Yes Yes Yes
Mazda CX7 Mazda CX7 2.2 MZR-CD 173hp Denso R2AX CAN Yes Yes Yes
MCC-Smart Smart 600cc Bosch MEG1.0 K-Line No Yes Checksum Button
MCC-Smart Smart 700cc Bosch MEG1.1 K-Line No Yes Checksum Button
MCC-Smart Smart 800cc Bosch EDG15C5 K-Line Yes Yes Checksum Button
MCC-Smart ForTwo 1.5l Cdi Bosch EDG16CP31/32 K-Line/CAN Yes Yes Yes
MCC-Smart ForFour 1.5l Cdi Bosch EDG16CP31/32 K-Line/CAN Yes Yes Yes
Mercedes CLK CLK 2.7 CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes CLK CLK 2.2 CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes CLK CLK 3.0 V6 CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes CLK CLK 200K 1.8 (W20
Siemens SIM4SE K-Line Yes Yes Yes
Mercedes CLK CLK 200K 2.0 (W20
Siemens SIM4SE K-Line Yes Yes Yes
Mercedes CLK CLK 200K 1.8 (W209) Siemens SIM4LKE K-Line Yes Yes Checksum Button
Mercedes CLK CLK 320 3.2 (W20
Bosch ME2.8 K-Line No Yes Yes
Mercedes CLK CLK 430 4.3 (W20
Bosch ME2.8 K-Line No Yes Yes
Mercedes CLK CLK 55 5.5 (W20
Bosch ME2.8 K-Line No Yes Yes
Mercedes CLK CLK 240 2.6 (W209) Bosch ME2.8 K-Line No Yes Yes
Mercedes CLK CLK 320 3.2 (W209) Bosch ME2.8 K-Line No Yes Yes
Mercedes CLK CLK 500 5.0 (W209) Bosch ME2.8 K-Line No Yes Yes
Mercedes CLK CLK 55 5.5 (W209) Bosch ME2.8 K-Line No Yes Yes
Mercedes CLK CLK 280 3.0 (W209) Bosch ME9.7 CAN No Yes Yes
Mercedes CLK CLK 350 3.5 (W209) Bosch ME9.7 CAN No Yes Yes
Mercedes CLK CLK 500 5.5 (W209) Bosch ME9.7 CAN No Yes Yes
Mercedes CLK CLK 200 2.0 (W20
Bosch ME2.1 K-Line Yes Yes Yes
Mercedes CLS CLS 3.0 V6 CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes CLS CLS 500 5.0 (W219) Bosch ME2.8 K-Line No Yes Yes
Mercedes CLS CLS 280 3.0 Bosch ME9.7 CAN No Yes Yes
Mercedes CLS CLK 300 3.0 Bosch ME9.7 CAN No Yes Yes
Mercedes CLS CLK 350 3.5 Bosch ME9.7 CAN No Yes Yes
Mercedes CLS CLK 500 5.5 Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-A A160 2.0 CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-A A160 2.0 CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-A A160 2.0 CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-A A170 2.0 CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-A A170 1.7 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Mercedes Klasse-A A180 2.0 CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-A A180 2.0 CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-A A200 2.0 CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-A A200 2.0 CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-B B180 2.0 CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-B B180 2.0 CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-B B200 2.0 CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-B B200 2.0 CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-B B200 2.0 CDI Bosch EDC16C32 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C 2.0 (W201) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 2.0 (W202) CDI Bosch EDC15C5 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 2.0 (W203) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 2.2 (W201) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 2.0 (W202) CDI Bosch EDC15C5 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 2.2 (W203) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 2.7 (W201) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 2.7 (W203) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 3.0 (W201) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 3.2 (W201) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C 3.2 (W203) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C C200 2.0 (W203) CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C C200 2.0 (W203) CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C C220 2.2 (W203) CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C C220 2.2 (W203) CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C C270 2.7 (W203) CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C C270 2.7 (W203) CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C C280 3.0 (W203) CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C C320 3.2 (W203) CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C C320 3.0 (W203) CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C C320 3.0 (W203) CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-C 3.0 AMG CDI (W203) Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-C C160K 1.8 (W203) Siemens SIM4LE K-Line Yes Yes Yes
Mercedes Klasse-C C180K 1.8 (W203) Siemens SIM4LE K-Line Yes Yes Yes
Mercedes Klasse-C C180K 1.8 (W203) Siemens SIM4SE K-Line Yes Yes Yes
Mercedes Klasse-C C180K 2.0 (W203) Siemens SIM4SE K-Line Yes Yes Yes
Mercedes Klasse-C C200K EVO 2.0 (W202) Siemens SIM4LE K-Line Yes Yes Yes
Mercedes Klasse-C C200K 1.8 (W203) Siemens SIM4LE K-Line Yes Yes Yes
Mercedes Klasse-C C200K EVO 2.0 (W203) Siemens SIM4LE K-Line Yes Yes Yes
Mercedes Klasse-C C230K 2.3 (W203) Siemens SIM4SE K-Line Yes Yes Yes
Mercedes Klasse-C C180K 1.8 (W203) Siemens SIM4LKE K-Line Yes Yes Checksum Button
Mercedes Klasse-C C200K 1.8 (W203) Siemens SIM4LKE K-Line Yes Yes Checksum Button
Mercedes Klasse-C C280 2.8 (W202) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-C C43 4.3 (W202) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-C C55 5.5 (W202) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-C C240 2.6 (W203) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-C C320 3.2 (W203) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-C C55 5.5 (W203) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-C C230 2.5 (W203) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-C C280 3.0 (W203) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-C C350 3.5 (W203) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-C C280 3.0 (W204) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-C C350 3.5 (W204) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-C C200 2.0 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-C C230 2.3 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-C C180 2.0 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-E 2.0 (W210) CDI Bosch EDC15C5 K-Line Yes Yes Checksum Button
Mercedes Klasse-E 2.0 (W210) CDI Bosch EDC15C5 K-Line Yes Yes Checksum Button
Mercedes Klasse-E 2.0 (W210) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-E 2.2 (W210) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-E 2.7 (W210) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-E 3.0 (W210) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-E 3.2 (W201) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-E 3.2 (W210) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-E E200 2.0 CDI (W211) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E200 2.0 CDI (W211) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E220 2.2 CDI (W211) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E220 2.2 CDI (W211) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E270 2.7 CDI (W211) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E270 2.7 CDI (W211) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E270 2.8 CDI (W211) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E270 2.8 CDI (W211) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E280 3.0 CDI (W211) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E280 3.0 CDI (W211) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E280 3.0 CDI (W211) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E320 3.0 CDI (W211) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E320 3.0 CDI (W211) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E320 3.2 CDI (W211) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E320 3.2 CDI (W211) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E320 3.2 CDI (W211) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-E E200 2.0 (W210) Siemens SIM4SE K-Line Yes Yes Yes
Mercedes Klasse-E E200 2.0 (W211) Siemens SIM4SE K-Line Yes Yes Yes
Mercedes Klasse-E E280 2.8 (W210) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-E E320 3.2 (W210) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-E E430 4.3 (W210) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-E E55 5.5 (W210) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-E E240 2.6 (W211) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-E E320 3.2 (W211) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-E E500 5.0 (W211) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-E E280 3.0 Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-E E350 3.5 Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-E E500 5.5 Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-E E200 2.0 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-E E320 3.2 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-E E420 4.2 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-E E500 5.0 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-G G320 3.2 (W463) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-G G500 5.0 (W463) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-G G55 5.5 (W163) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-G G500 5.5 Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-M 2.7 CDI (W163) Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-M 3.2 CDI (W163) Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-M M320 3.2 (W163) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-M M350 3.5 (W163) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-M M430 4.3 (W163) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-M M500 5.0 (W163) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-M M55 5.5 (W163) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-M G320 3.2 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-ML 2.7 CDI (W164) Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-ML 3.2 CDI (W164) Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-ML ML280 3.0 CDI (W164) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML280 3.0 CDI (W164) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML280 3.0 CDI (W164) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML320 3.0 CDI (W164) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML320 3.0 CDI (W164) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML320 3.0 CDI (W164) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML320 3.2 CDI (W164) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML320 3.2 CDI (W164) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML320 3.2 CDI (W164) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML-Class 4.2 V8 CDI (W164) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-ML ML500 5.0 (W164) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-ML ML350 3.5 Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-ML ML500 5.5 Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-ML ML320 3.2 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-ML ML430 4.3 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-ML ML500 5.0 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-ML ML55 5.5 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-R R280 3.0 CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-R R320 3.0 CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-R R500 5.0 (W251) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-S S320 3.2 (W220) CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Klasse-S S320 3.0 CDI (W221) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-S S320 3.2 CDI (W220) Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Klasse-S S320 3.2 CDI (W220) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-S S320 3.2 CDI (W220) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-S S420 4.2 V8 CDI (W221) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Klasse-S S280 2.8 (W220) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-S S320 3.2 (W220) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-S S350 3.5 (W220) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-S S430 4.3 (W220) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-S S500 5.0 (W220) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-S S55 5.5 (W220) Bosch ME2.8 K-Line No Yes Yes
Mercedes Klasse-S S300 3.0 (W221) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-S S350 3.5 (W221) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-S S400 3.5 (W221) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-S S450 4.6 (W221) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-S S500 5.0 (W221) Bosch ME9.7 CAN No Yes Yes
Mercedes Klasse-S S280 2.8 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-S S320 3.2 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-S S430 4.3 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-S S500 5.0 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Klasse-V 2.2 CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes SLK SLK200K 1.8 (R171) Siemens SIM4SE K-Line Yes Yes Yes
Mercedes SLK SLK200K 2.0 (R170) Siemens SIM4SE K-Line Yes Yes Yes
Mercedes SLK SLK200K 1.8 (R171) Siemens SIM4LKE K-Line Yes Yes Checksum Button
Mercedes SLK SLK320 3.2 (W170) Bosch ME2.8 K-Line No Yes Yes
Mercedes SLK SLK55 5.5 (W171) Bosch ME2.8 K-Line No Yes Yes
Mercedes SLK SLK 280 3.0 Bosch ME9.7 CAN No Yes Yes
Mercedes SLK SLK 300 3.0 Bosch ME9.7 CAN No Yes Yes
Mercedes SLK SLK 350 3.5 Bosch ME9.7 CAN No Yes Yes
Mercedes SLK SLK 200 2.0 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes SLK SLK 230 2.3 Bosch ME2.1 K-Line Yes Yes Yes
Mercedes Sprinter 2.0 CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Sprinter 2.2 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Mercedes Sprinter 2.2 CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Sprinter 2.2 CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Sprinter 2.7 CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Sprinter 3.0 V6 CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Vaneo 2.2 CDI Bosch EDC15C6 K-Line Yes Yes Checksum Button
Mercedes Vaneo 2.2 CDI Bosch EDC16C2/3/4 K-Line/CAN Yes Yes Yes
Mercedes Vaneo 2.2 CDI Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Vaneo 3.0 CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Viano 3.0 V6 CDI Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
Mercedes Vito 2.2 CDI (W63
Bosch EDC15C5 K-Line Yes Yes Checksum Button
Mercedes Vito 2.2 CDI (W639) Bosch EDC16C31 K-Line/CAN Yes Yes Yes
Mercedes Vito 3.0 CDI (W639) Bosch EDC16CP31 K-Line/CAN Yes Yes Yes
MG ZT 2.0 CDTI Bosch DDE4.0 K-Line Yes Yes Yes
Mini Cooper 1.6 Siemens EMS 2 K-Line Yes Yes Checksum Button
Mini Cooper 1.6 S Siemens EMS 2 K-Line Yes Yes Checksum Button
Mini Cooper S 1.6 Siemens EMS 2 K-Line Yes Yes Checksum Button
Mini Cooper S 1.6 S Siemens EMS 2 K-Line Yes Yes Checksum Button
Mini One 1.4D Bosch DDE4.0 K-Line Yes Yes Yes
Mini One 1.6 Siemens EMS 2 K-Line Yes Yes Checksum Button
Mini One 1.6 D Bosch EDC16C35 K-Line_Fast/CAN Yes Yes Yes
Mitsubishi Carisma 1.9 CDI Bosch EDC15C3 K-Line Yes Yes Checksum Button
Mitsubishi Colt 1.5l DI-D Bosch EDG16CP31/32 K-Line/CAN Yes Yes Yes
Mitsubishi Grandis 2.0 16V DI-D Bosch EDC16U31 CAN Yes Yes Yes
Mitsubishi L200 2.5L DI-D 136hp Denso 4D56/4M41 CAN Yes Yes Yes
Mitsubishi Lancer 2.0 16V DI-D Bosch EDC16U31 CAN Yes Yes Yes
Mitsubishi Outlander 2.0 16V DI-D Bosch EDC16U31 CAN Yes Yes Yes
Mitsubishi Pajero 2.5L DI-D 136hp Denso 4D56/4M41 CAN Yes Yes Yes
Mitsubishi SpaceStar 1.9 CDI Bosch EDC15C3 K-Line Yes Yes Checksum Button
Nissan Almera 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Nissan Interstar 1.9 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Nissan Interstar 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Nissan Interstar 2.5 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Nissan Interstar 2.5 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Nissan Juke 1.5 DCI Siemens SID305 Tricore CAN Yes Yes Yes
Nissan Primastar 1.9 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Nissan Primastar 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Nissan Primastar 2.0 DCI Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Nissan Primastar EDC16 Bosch Nozzle Codes K-Line/CAN Yes Yes Yes
Nissan Qashqai 1.5 DCI Siemens SID305 Tricore CAN Yes Yes Yes
Nissan Qashqai 1.5 (106hp) DCi Siemens SID304 CAN Yes Yes Yes
Nissan Qashqai 2.0 DCI Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Nissan Qashqai EDC16 Bosch Nozzle Codes K-Line/CAN Yes Yes Yes
Nissan X-Trail 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Opel Agila 1.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Agila 1.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Opel Agila 1.0i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Agila 1.2 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Agila 1.2 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Opel Agila 1.2i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Agila 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Opel Agila 1.3 16v CDTi Marelli MJD 602 K-Line Yes Yes Yes
Opel Agila 1.3 16v CDTI Marelli MJD 602-3 CAN Yes Yes Yes
Opel Astra 1.0 8v Bosch M1.5.5 K-Line No No Checksum Button
Opel Astra 1.2 16V Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Astra 1.2 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Opel Astra 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Opel Astra 1.3 16v CDTI Marelli MJD 602-3 CAN Yes Yes Yes
Opel Astra 1.4 16V Delco Multec K-Line No No Checksum Button
Opel Astra 1.4i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Astra 1.6 16V Delco Multec K-Line No No Checksum Button
Opel Astra 2.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Astra 2.0 16v Turbo Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Astra 2.0i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Astra 1.7 16V DTI Bosch EDC15M K-Line No No Checksum Button
Opel Astra 2.0 16V DTI Bosch EDC15M K-Line No No Checksum Button
Opel Astra 2.2 16V DTI Bosch EDC15M K-Line No No Checksum Button
Opel Astra 1.7 16V DT Delco LVP4 K-Line No No Checksum Button
Opel Astra 1.7 16V DTI Delco LVP11 K-Line No No Checksum Button
Opel Astra 1.8 16V Siemens Simtec K-Line No No Checksum Button
Opel Astra 2.0 16V Siemens Simtec K-Line No No Checksum Button
Opel Astra 1.8 16V Siemens Simtec 70 K-Line No No Checksum Button
Opel Astra 2.0 16V Siemens Simtec 70 K-Line No No Checksum Button
Opel Astra 1.8 16V Siemens Simtec 90 K-Line No No Checksum Button
Opel Astra 2.0 16V Siemens Simtec 90 K-Line No No Checksum Button
Opel Astra 2.2 SRI Delco GM PT K-Line No No Checksum Button
Opel Astra 1.3 16v CDTI Marelli Multijet K-Line Yes Yes Yes
Opel Astra 1.7 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Opel Astra 1.7 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Opel Astra 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Opel Astra 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Opel Astra 1.7 16V CDTI 110hp 2010 on Denso AX36 CAN Yes Yes Yes
Opel Astra 1.7 16V CDTI 125hp 2010 on Denso AX36 CAN Yes Yes Yes
Opel Astra 1.7 16V CDTI 110hp 2010 Denso MFDX CAN Yes Yes Yes
Opel Astra 1.7 16V CDTI 125hp 2010 Denso MFDX CAN Yes Yes Yes
Opel Astra 2.0 16V CDTI Bosch PSG16 CAN Yes Yes Yes
Opel Corsa 1.0 8v Bosch M1.5.5 K-Line No No Checksum Button
Opel Corsa 1.0 12v Bosch M1.5.5 K-Line Yes Yes Yes
Opel Corsa 1.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Corsa 1.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Opel Corsa 1.0i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Corsa 1.2 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Corsa 1.2 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Opel Corsa 1.2i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Corsa 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Opel Corsa 1.3 16v CDTi Marelli MJD 602 K-Line Yes Yes Yes
Opel Corsa 1.3 16v CDTI Marelli MJD 602/3 CAN Yes Yes Yes
Opel Corsa 1.4 16V Delco Multec K-Line No No Checksum Button
Opel Corsa 1.4i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Corsa 1.7 16V DT Delco LVP4 K-Line No No Checksum Button
Opel Corsa 1.7 16V DTI Delco LVP11 K-Line No No Checksum Button
Opel Corsa 1.7 16V DTI Denso LRDX Hybrid CAN Yes Yes Yes
Opel Corsa 1.7 16V CDTI 110hp 2010 Denso AP47 CAN Yes Yes Yes
Opel Corsa 1.7 16V CDTI 125hp 2010 Denso AP47 CAN Yes Yes Yes
Opel Combo 1.3 16v CDTI Marelli Multijet 6JO K-Line Yes Yes Yes
Opel Combo 1.3 16v CDTi Marelli MJD 602 K-Line Yes Yes Yes
Opel Combo 1.3 16v CDTI Marelli MJD 602/3 CAN Yes Yes Yes
Opel Combo 1.7 16V DTI Bosch EDC15M K-Line No No Checksum Button
Opel Combo 1.7 16V DT Delco LVP4 K-Line No No Checksum Button
Opel Combo 1.7 16V DTI Delco LVP11 K-Line No No Checksum Button
Opel Frontera 2.2 16V DTI Bosch EDC15M K-Line No No Checksum Button
Opel Meriva 1.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Meriva 1.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Opel Meriva 1.2 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Meriva 1.2 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Opel Meriva 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Opel Meriva 1.3 16v CDTI Marelli MJD 602/3 KLine Yes Yes Yes
Opel Meriva 1.3 16v CDTI Marelli MJD 602/3 CAN Yes Yes Yes
Opel Meriva 1.4i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Meriva 1.7 16V DTI Delco LVP11 K-Line No No Checksum Button
Opel Meriva 1.7 16V DTI Denso LRDX Hybrid CAN Yes Yes Yes
Opel Meriva 1.7 16V CDTI 110hp 2010 Denso AP47 CAN Yes Yes Yes
Opel Meriva 1.7 16V CDTI 125hp 2010 Denso AP47 CAN Yes Yes Yes
Opel Omega 2.0 16V Siemens Simtec K-Line No No Checksum Button
Opel Omega 2.0 16V DTI Bosch EDC15M K-Line No No Checksum Button
Opel Omega 2.2 16V DTI Bosch EDC15M K-Line No No Checksum Button
Opel Omega 2.5 V6 Bosch M2.8.3 K-Line No No Checksum Button
Opel Signum 2.2 SRI Delco GM PT K-Line No No Checksum Button
Opel Signum 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Opel Signum 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Opel Sintra 2.2 16V DTI Bosch EDC15M K-Line No No Checksum Button
Opel Tigra 1.0i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Tigra 1.2i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Tigra 1.4i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Tigra 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Opel Tigra 1.3 16v CDTI Marelli MJD 602/3 KLine Yes Yes Yes
Opel Tigra 1.3 16v CDTI Marelli MJD 602/3 CAN Yes Yes Yes
Opel Vectra 2.2 SRI Delco GM PT K-Line No No Checksum Button
Opel Vectra 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Opel Vectra 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Opel Vivaro 1.9 TD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Opel Vivaro 2.5 TD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Opel VX220 2.0 16v Turbo Bosch ME1.5.5 K-Line Yes Yes Yes
Opel VX220 2.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Opel VX220 2.2L Delco GM PT K-Line No No Checksum Button
Opel Zafira 1.8 16V Siemens Simtec K-Line No No Checksum Button
Opel Zafira 2.0 16V Siemens Simtec K-Line No No Checksum Button
Opel Zafira 1.8 16V SIemens Simtec 70 K-Line No No Checksum Button
Opel Zafira 2.0 16V Siemens Simtec 70 K-Line No No Checksum Button
Opel Zafira 1.8 16V Siemens Simtec 90 K-Line No No Checksum Button
Opel Zafira 2.0 16V Siemens Simtec 90 K-Line No No Checksum Button
Opel Zafira 2.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Zafira 2.0 16v Turbo Bosch ME1.5.5 K-Line Yes Yes Yes
Opel Zafira 2.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Opel Zafira 2.0i Bosch ME7.6.2 CAN Yes Yes Yes
Opel Zafira 2.0 TD Bosch EDC15M K-Line No No Checksum Button
Opel Zafira 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Opel Zafira 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Opel Zafira 1.7 16V CDTI 110hp 2010 on Denso AX36 CAN Yes Yes Yes
Opel Zafira 1.7 16V CDTI 125hp 2010 on Denso AX36 CAN Yes Yes Yes
Opel Zafira 2.0 16V CDTI Bosch PSG16 CAN Yes Yes Yes
Opel Zafira 2.2 16V CDTI Bosch PSG16 CAN Yes Yes Yes
Peugeot 106 1.1L Bosch MP7.4.4 K-Line Yes Yes Checksum Button
Peugeot 106 1.4L 16v Marelli 6LPA K-Line Yes Yes Checksum Button
Peugeot 106 1.6L Bosch MP7.4.4 K-Line Yes Yes Checksum Button
Peugeot 1007 1.4 HDI Siemens SID 804 K-Line Yes Yes Yes
Peugeot 206 1.4L 16v Marelli 6LPA K-Line Yes Yes Checksum Button
Peugeot 206 1.6L Bosch MP7.4.4 K-Line Yes Yes Checksum Button
Peugeot 206 1.4 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Peugeot 206 1.4 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 206 1.6 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Peugeot 206 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 206 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 206 1.4 HDI Siemens SID 804 K-Line Yes Yes Yes
Peugeot 206 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Peugeot 207 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 207 1.6 Turbo Bosch MED17.4 CAN Yes Yes Yes
Peugeot 207 RC 1.6 Turbo Bosch MED17.4 CAN Yes Yes Yes
Peugeot 306 1.4 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Peugeot 306 1.4 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 306 1.6L Bosch MP7.4.4 K-Line Yes Yes Checksum Button
Peugeot 306 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 306 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 306 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Peugeot 307 1.4 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Peugeot 307 1.4 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 307 1.6 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Peugeot 307 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 307 2.0 HDI Siemens SID801 K-Line Yes Yes Yes
Peugeot 307 2.0 HDI Siemens SID801A K-Line Yes Yes Yes
Peugeot 307 2.0 HDI Siemens SID804 K-Line Yes Yes Yes
Peugeot 307 2.0 HDI Siemens SID803A K-Line/CAN Yes Yes Yes
Peugeot 307 2.0 HDI Siemens SID803 K-Line Yes Yes Yes
Peugeot 307 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 307 2.0L 16v Marelli 6LPA K-Line Yes Yes Checksum Button
Peugeot 307 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Peugeot 308 1.6 Turbo Bosch MED17.4 CAN Yes Yes Yes
Peugeot 308 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 3008 2.0 HDI Delphi DCM 3.5 CAN Yes Yes Yes
Peugeot 406 1.6L Bosch MP7.4.4 K-Line Yes Yes Checksum Button
Peugeot 406 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 406 2.2 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 406 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Peugeot 407 1.6 HDI Bosch EDC16C3 K-Line Yes Yes Yes
Peugeot 407 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 407 2.0 HDI Siemens SID803A K-Line/CAN Yes Yes Yes
Peugeot 407 2.0 HDI Siemens SID803 K-Line Yes Yes Yes
Peugeot 407 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 407 2.2 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 407 2.0L 16v Marelli 6LPA K-Line Yes Yes Checksum Button
Peugeot 407 2.0 HDI Delphi DCM 3.5 CAN Yes Yes Yes
Peugeot 5008 2.0 HDI Delphi DCM 3.5 CAN Yes Yes Yes
Peugeot 607 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 607 2.2 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 806 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 807 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot 807 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 807 2.2 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot 807 2.2 TD Bosch EDC16CP39 K-Line/CAN Yes Yes Yes
Peugeot Boxer 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot Boxer 2.2 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot Boxer 2.8 HDI Bosch EDC15C7 K-Line Yes Yes Checksum Button
Peugeot Boxer 3.0 HDI Bosch EDC16C39 CAN Yes Yes Yes
Peugeot Boxer 2.0 HDI Siemens SID803A K-Line/CAN Yes Yes Yes
Peugeot Expert 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot Expert 2.0 HDI Siemens SID803A K-Line/CAN Yes Yes Yes
Peugeot Partner 1.6 HDI FAP Bosch EDC16C34 K-Line/CAN Yes Yes Yes
Peugeot Partner 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot Partner 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Peugeot Ranch 2.0 HDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Peugeot Ranch 2.0 HDI Siemens SID 801/801A K-Line Yes Yes Yes
Peugeot Ranch 2.0 HDI Siemens SID803A K-Line/CAN Yes Yes Yes
Peugeot RCZ 2.0 HDI Delphi DCM 3.5 CAN Yes Yes Yes
Porsche Boxster 2.5L (986) Bosch M5.2.2 K-Line Yes Yes Checksum Button
Porsche Boxster 2.7L (986) Bosch ME7.2 K-Line Yes Yes Yes
Porsche Boxster 3.2L (986) Bosch ME7.2 K-Line Yes Yes Yes
Porsche Cayman 2.7L Bosch ME7.8.4 K-Line Yes Yes Yes
Porsche Cayman 3.4L Bosch ME7.8.4 K-Line Yes Yes Yes
Porsche 996 3.4L Bosch M5.2.2 K-Line Yes Yes Checksum Button
Porsche 996 3.4L (Carrera) Bosch ME7.2 K-Line Yes Yes Yes
Porsche 996 3.6L (Carrera) Bosch ME7.2 K-Line Yes Yes Yes
Porsche 996 3.6L Twin Turbo GT2 Bosch M5.2.2 K-Line Yes Yes Checksum Button
Porsche 996 3.6L GT3 Bosch M5.2.2 K-Line Yes Yes Checksum Button
Porsche 996 3.4L Bosch ME7.8.4 K-Line Yes Yes Yes
Porsche 996 3.6L Bosch ME7.8.4 K-Line Yes Yes Yes
Porsche 996 3.6L Twin Turbo Bosch ME7.8.4 K-Line Yes Yes Yes
Porsche 996 3.6L GT2 Twin Turbo Bosch ME7.8.4 K-Line Yes Yes Yes
Porsche 996 3.6L GT3 Bosch ME7.8.4 K-Line Yes Yes Yes
Porsche 997 3.6L Bosch ME7.8.4 K-Line Yes Yes Yes
Porsche 997 3.8L Bosch ME7.8.4 K-Line Yes Yes Yes
Porsche 997 3.8L GT3RS Bosch ME7.8.1 K-Line/CAN Yes Yes Yes
Porsche 997 3.8L GT2 Turbo Bosch ME7.8.2 K-Line/CAN Yes Yes Yes
Porsche 997 3.8L Twin Turbo Bosch ME7.8.2 K-Line/CAN Yes Yes Yes
Porsche Cayenne 3.2L (995) Bosch ME7.2 K-Line Yes Yes Yes
Porsche Cayenne 3.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Porsche Cayenne 4.5L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Porsche Cayenne 4.5L Turbo Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Porsche Cayenne 4.5L Turbo S Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Renault Avantime 2.2 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Clio 1.5 Euro 3 Delphi DDCR K-Line Yes Yes Yes
Renault Clio 1.5 Euro 4 Delphi DCM 1.2 K-Line Yes Yes Yes
Renault Clio 2.0 16v 197hp Sagem S3000 K-Line/CAN Yes Yes Yes
Renault Clio 2.0 16v 172/182hp Siemens Sirius 34 K-Line Yes Yes Checksum Button
Renault Clio 2.0 16v 172 Fase1 Siemens Sirius 32 K-Line Yes Yes Checksum Button
Renault Clio RS 1.6T 200hp Siemens EMS3150 CAN Yes Yes Yes
Renault Espace 1.9 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Espace 2.0 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Espace 2.2 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Espace 2.2 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Kangoo 1.5 Euro 3 Delphi DDCR K-Line Yes Yes Checksum Button
Renault Kangoo 1.5 Euro 4 Delphi DCM 1.2 K-Line Yes Yes Yes
Renault Kangoo 1.9 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Koleos 2.0 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Laguna 1.9 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Laguna 2.2 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Laguna 1.9 DCi Bosch EDC16C3 K-Line/CAN Yes Yes Yes
Renault Laguna 2.0 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Laguna 2.2 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Laguna EDC16 Bosch Nozzle Codes K-Line/CAN Yes Yes Yes
Renault Master 1.9 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Master 2.2 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Master 2.0 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Master 2.5 DCi Bosch EDC15C13 K-Line Yes Yes Checksum Button
Renault Master EDC16 Bosch Nozzle Codes K-Line/CAN Yes Yes Yes
Renault Megane 1.5 Euro 3 Delphi DDCR K-Line Yes Yes Yes
Renault Megane 1.5 Euro 4 Delphi DCM 1.2 K-Line Yes Yes Yes
Renault Megane 1.5 (106hp) DCi Siemens SID304 CAN Yes Yes Yes
Renault Megane 1.5 DCi Siemens SID305 Tricore CAN Yes Yes Yes
Renault Megane 1.9 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Megane 1.9 DCi Bosch EDC16C3 K-Line/CAN Yes Yes Yes
Renault Megane 2.0 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Megane EDC16 Bosch Nozzle Codes K-Line/CAN Yes Yes Yes
Renault Megane 2.0T 225hp Sagem S3000 K-Line/CAN Yes Yes Yes
Renault Megane 2.0T 250hp Continental EMS3130 CAN Yes Yes Yes
Renault Modus 1.5 Euro 3 Delphi DDCR K-Line Yes Yes Yes
Renault Modus 1.5 Euro 4 Delphi DCM 1.2 K-Line Yes Yes Yes
Renault Scenic 1.4 16v Sagem S3000 K-Line/CAN Yes Yes Yes
Renault Scenic 1.6 16v Sagem S3000 K-Line/CAN Yes Yes Yes
Renault Scenic 2.0 16v Sagem S3000 K-Line/CAN Yes Yes Yes
Renault Scenic 1.5 Euro 3 Delphi DDCR K-Line Yes Yes Yes
Renault Scenic 1.5 Euro 4 Delphi DCM 1.2 K-Line Yes Yes Yes
Renault Scenic 1.5 (106hp) DCi Siemens SID304 CAN Yes Yes Yes
Renault Scenic 1.5 DCi Siemens SID305 Tricore CAN Yes Yes Yes
Renault Scenic 1.9 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Scenic 1.9 DCi Bosch EDC16C3 K-Line/CAN Yes Yes Yes
Renault Scenic 1.9 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Scenic 2.0 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Scenic EDC16 Bosch Nozzle Codes K-Line/CAN Yes Yes Yes
Renault Twingo 1.6 Rs 16v Siemens Sirius 32 CAN Yes Yes Checksum Button
Renault Traffic 1.9 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Traffic 2.2 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Traffic 2.0 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Traffic 2.5 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Traffic EDC16 Bosch Nozzle Codes K-Line/CAN Yes Yes Yes
Renault Vel Satis 2.2 DCR Bosch EDC15C2 K-Line Yes Yes Checksum Button
Renault Vel Satis 2.2 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Vel Satis 2.0 DCi Bosch EDC16CP33 K-Line/CAN Yes Yes Yes
Renault Vel Satis EDC16 Bosch Nozzle Codes K-Line/CAN Yes Yes Yes
Rover Rover 75 2.0 CDT Bosch DDE4.0 K-Line Yes Yes Yes
Rover Rover 75 Tourer 2.0 CDT Bosch DDE4.0 K-Line Yes Yes Yes
Saab 93 2.2 16V TiD Bosch EDC15M K-Line No No Checksum Button
Saab 93 1.9 16V TiD Bosch EDC16C39 CAN Yes Yes Yes
Saab 93 1.8 T Saab Trionic-7 CAN Yes Yes Checksum Button
Saab 93 1.8 T Saab Trionic-8 CAN Yes Yes Checksum Button
Saab 93 2.0 T Saab Trionic-7 CAN Yes Yes Checksum Button
Saab 93 2.0 T Saab Trionic-8 CAN Yes Yes Checksum Button
Saab 93 2.3 T Saab Trionic-7 CAN Yes Yes Checksum Button
Saab 95 1.9 16V TiD Bosch EDC16C39 CAN Yes Yes Yes
Seat Alhambra 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Seat Alhambra 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Seat Alhambra 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Seat Alhambra 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Seat Alhambra 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Seat Alhambra 1.9 TDI Bosch EDC16U1 K-Line Yes Yes Yes
Seat Alhambra 2.0 TDI Bosch EDC16U1 K-Line Yes Yes Yes
Seat Alhambra 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Seat Alhambra ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Seat Alhambra ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Seat Alhambra ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Seat Alhambra ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Seat Altea 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Seat Altea 1.9 TDI Bosch EDC16U1 K-Line Yes Yes Yes
Seat Altea 2.0 TDI Bosch EDC16U1 K-Line Yes Yes Yes
Seat Altea 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Seat Altea 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Seat Altea 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Seat Altea ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Seat Altea ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Seat Altea ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Seat Altea ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Seat Cordoba 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Seat Cordoba 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Seat Cordoba 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Seat Cordoba 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Seat Exeo ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Seat Exeo ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Seat Exeo ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Seat Exeo ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Seat Ibiza 1.4 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Seat Ibiza 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Seat Ibiza 1.9 SDI Bosch EDC15 K-Line Yes Yes Checksum Button
Seat Ibiza 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Seat Ibiza 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Seat Ibiza 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Seat Ibiza ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Seat Ibiza ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Seat Ibiza ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Seat Ibiza ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Seat Leon 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Seat Leon 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Seat Leon 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Seat Leon 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Seat Leon 1.9 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Seat Leon 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Seat Leon 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Seat Leon 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Seat Leon 2.0 20v Bosch ME7.5 K-Line Yes Yes Checksum Button
Seat Leon 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Seat Leon 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Seat Leon 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Seat Leon 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Seat Leon 2.0L Bosch M5.92 K-Line No Yes Checksum Button
Seat Leon ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Seat Leon ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Seat Leon ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Seat Leon ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Seat Toledo 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Seat Toledo 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Seat Toledo 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Seat Toledo 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Seat Toledo 1.9 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Seat Toledo 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Seat Toledo 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Seat Toledo 2.3L Bosch ME7.1 K-Line Yes Yes Checksum Button
Seat Toledo 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Seat Toledo 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Seat Toledo 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Seat Toledo 2.3L Bosch M5.92 K-Line No Yes Checksum Button
Skoda Fabia 1.4 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Skoda Fabia 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Skoda Fabia 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Skoda Fabia 1.9 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Skoda Fabia ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Skoda Fabia ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Skoda Fabia ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Skoda Fabia ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Skoda Octavia 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Skoda Octavia 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Skoda Octavia 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Skoda Octavia 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Skoda Octavia 1.9 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Skoda Octavia 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Skoda Octavia 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Skoda Octavia 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Skoda Octavia 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Skoda Octavia 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Skoda Octavia 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Skoda Octavia 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Skoda Octavia 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Skoda Octavia 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Skoda Octavia ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Skoda Octavia ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Skoda Octavia ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Skoda Octavia ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Skoda Roomster 1.4 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Skoda Roomster 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Skoda Roomster 1.9 TDI Bosch EDC16U1 K-Line Yes Yes Yes
Skoda Roomster 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Skoda Roomster ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Skoda Roomster ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Skoda Roomster ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Skoda Roomster ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Skoda Superb 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Skoda Superb 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Skoda Superb 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Skoda Superb 1.9 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Skoda Superb 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Skoda Superb 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Skoda Superb 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Skoda Superb ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Skoda Superb ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Skoda Superb ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Skoda Superb ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Skoda Yeti 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Suzuki Gran Vitara 2.0 CDI Bosch EDC15C2 K-Line Yes Yes Checksum Button
Suzuki Ignis 1.3 16v DDiS Marelli MJD 6JO K-Line Yes Yes Yes
Suzuki Ignis 1.3 16v DDis Marelli MJD 602/3 CAN Yes Yes Yes
Suzuki Sx4 1.6 DDis Bosch EDC16C39 K-Line Yes Yes Yes
Suzuki Swift 1.3 16v DDiS Marelli MJD 6JO K-Line Yes Yes Yes
Suzuki Swift 1.3 16v DDiS Marelli MJD 602/3 CAN Yes Yes Yes
Suzuki Wagon-R 1.3 16v DDiS Marelli MJD 6JO K-Line Yes Yes Yes
Suzuki Wagon-R 1.3 16v DDiS Marelli MJD 602/3 CAN Yes Yes Yes
Vauxhall Agila 1.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Agila 1.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Vauxhall Agila 1.0i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Agila 1.2 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Agila 1.2 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Vauxhall Agila 1.2i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Agila 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Vauxhall Agila 1.3 16v CDTi Marelli MJD 602 K-Line Yes Yes Yes
Vauxhall Agila 1.3 16v CDTI Marelli MJD 602-3 CAN Yes Yes Yes
Vauxhall Astra 1.0 8v Bosch M1.5.5 K-Line No No Checksum Button
Vauxhall Astra 1.2 16V Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Astra 1.2 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Vauxhall Astra 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Vauxhall Astra 1.3 16v CDTI Marelli MJD 602-3 CAN Yes Yes Yes
Vauxhall Astra 1.4 16V Delco Multec K-Line No No Checksum Button
Vauxhall Astra 1.4i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Astra 1.6 16V Delco Multec K-Line No No Checksum Button
Vauxhall Astra 2.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Astra 2.0 16v Turbo Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Astra 2.0i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Astra 1.7 16V DTI Bosch EDC15M K-Line No No Checksum Button
Vauxhall Astra 2.0 16V DTI Bosch EDC15M K-Line No No Checksum Button
Vauxhall Astra 2.2 16V DTI Bosch EDC15M K-Line No No Checksum Button
Vauxhall Astra 1.7 16V DT Delco LVP4 K-Line No No Checksum Button
Vauxhall Astra 1.7 16V DTI Delco LVP11 K-Line No No Checksum Button
Vauxhall Astra 1.8 16V Siemens Simtec K-Line No No Checksum Button
Vauxhall Astra 2.0 16V Siemens Simtec K-Line No No Checksum Button
Vauxhall Astra 1.8 16V Siemens Simtec 70 K-Line No No Checksum Button
Vauxhall Astra 2.0 16V Siemens Simtec 70 K-Line No No Checksum Button
Vauxhall Astra 1.8 16V Siemens Simtec 90 K-Line No No Checksum Button
Vauxhall Astra 2.0 16V Siemens Simtec 90 K-Line No No Checksum Button
Vauxhall Astra 2.2 SRI Delco GM PT K-Line No No Checksum Button
Vauxhall Astra 1.3 16v CDTI Marelli Multijet K-Line Yes Yes Yes
Vauxhall Astra 1.7 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Vauxhall Astra 1.7 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Vauxhall Astra 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Vauxhall Astra 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Vauxhall Astra 1.7 16V CDTI 110hp 2010 on Denso AX36 CAN Yes Yes Yes
Vauxhall Astra 1.7 16V CDTI 125hp 2010 on Denso AX36 CAN Yes Yes Yes
Vauxhall Astra 1.7 16V CDTI 110hp 2010 Denso MFDX CAN Yes Yes Yes
Vauxhall Astra 1.7 16V CDTI 125hp 2010 Denso MFDX CAN Yes Yes Yes
Vauxhall Astra 2.0 16V CDTI Bosch PSG16 CAN Yes Yes Yes
Vauxhall Corsa 1.0 8v Bosch M1.5.5 K-Line No No Checksum Button
Vauxhall Corsa 1.0 12v Bosch M1.5.5 K-Line Yes Yes Yes
Vauxhall Corsa 1.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Corsa 1.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Vauxhall Corsa 1.0i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Corsa 1.2 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Corsa 1.2 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Vauxhall Corsa 1.2i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Corsa 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Vauxhall Corsa 1.3 16v CDTi Marelli MJD 602 K-Line Yes Yes Yes
Vauxhall Corsa 1.3 16v CDTI Marelli MJD 602/3 CAN Yes Yes Yes
Vauxhall Corsa 1.4 16V Delco Multec K-Line No No Checksum Button
Vauxhall Corsa 1.4i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Corsa 1.7 16V DT Delco LVP4 K-Line No No Checksum Button
Vauxhall Corsa 1.7 16V DTI Delco LVP11 K-Line No No Checksum Button
Vauxhall Corsa 1.7 16V DTI Denso LRDX Hybrid CAN Yes Yes Yes
Vauxhall Corsa 1.7 16V CDTI 110hp 2010 Denso AP47 CAN Yes Yes Yes
Vauxhall Corsa 1.7 16V CDTI 125hp 2010 Denso AP47 CAN Yes Yes Yes
Vauxhall Combo 1.3 16v CDTI Marelli Multijet 6JO K-Line Yes Yes Yes
Vauxhall Combo 1.3 16v CDTi Marelli MJD 602 K-Line Yes Yes Yes
Vauxhall Combo 1.3 16v CDTI Marelli MJD 602/3 CAN Yes Yes Yes
Vauxhall Combo 1.7 16V DTI Bosch EDC15M K-Line No No Checksum Button
Vauxhall Combo 1.7 16V DT Delco LVP4 K-Line No No Checksum Button
Vauxhall Combo 1.7 16V DTI Delco LVP11 K-Line No No Checksum Button
Vauxhall Frontera 2.2 16V DTI Bosch EDC15M K-Line No No Checksum Button
Vauxhall Meriva 1.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Meriva 1.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Vauxhall Meriva 1.2 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Meriva 1.2 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Vauxhall Meriva 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Vauxhall Meriva 1.3 16v CDTI Marelli MJD 602/3 KLine Yes Yes Yes
Vauxhall Meriva 1.3 16v CDTI Marelli MJD 602/3 CAN Yes Yes Yes
Vauxhall Meriva 1.4i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Meriva 1.7 16V DTI Delco LVP11 K-Line No No Checksum Button
Vauxhall Meriva 1.7 16V DTI Denso LRDX Hybrid CAN Yes Yes Yes
Vauxhall Meriva 1.7 16V CDTI 110hp 2010 Denso AP47 CAN Yes Yes Yes
Vauxhall Meriva 1.7 16V CDTI 125hp 2010 Denso AP47 CAN Yes Yes Yes
Vauxhall Omega 2.0 16V Siemens Simtec K-Line No No Checksum Button
Vauxhall Omega 2.0 16V DTI Bosch EDC15M K-Line No No Checksum Button
Vauxhall Omega 2.2 16V DTI Bosch EDC15M K-Line No No Checksum Button
Vauxhall Omega 2.5 V6 Bosch M2.8.3 K-Line No No Checksum Button
Vauxhall Signum 2.2 SRI Delco GM PT K-Line No No Checksum Button
Vauxhall Signum 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Vauxhall Signum 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Vauxhall Sintra 2.2 16V DTI Bosch EDC15M K-Line No No Checksum Button
Vauxhall Tigra 1.0i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Tigra 1.2i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Tigra 1.4i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Tigra 1.3 16v CDTI Marelli MJD 6JO K-Line Yes Yes Yes
Vauxhall Tigra 1.3 16v CDTI Marelli MJD 602/3 KLine Yes Yes Yes
Vauxhall Tigra 1.3 16v CDTI Marelli MJD 602/3 CAN Yes Yes Yes
Vauxhall Vectra 2.2 SRI Delco GM PT K-Line No No Checksum Button
Vauxhall Vectra 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Vauxhall Vectra 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Vauxhall Vivaro 1.9 TD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Vauxhall Vivaro 2.5 TD Bosch EDC15C2 K-Line Yes Yes Checksum Button
Vauxhall VX220 2.0 16v Turbo Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall VX220 2.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Vauxhall VX220 2.2L Delco GM PT K-Line No No Checksum Button
Vauxhall Zafira 1.8 16V Siemens Simtec K-Line No No Checksum Button
Vauxhall Zafira 2.0 16V Siemens Simtec K-Line No No Checksum Button
Vauxhall Zafira 1.8 16V SIemens Simtec 70 K-Line No No Checksum Button
Vauxhall Zafira 2.0 16V Siemens Simtec 70 K-Line No No Checksum Button
Vauxhall Zafira 1.8 16V Siemens Simtec 90 K-Line No No Checksum Button
Vauxhall Zafira 2.0 16V Siemens Simtec 90 K-Line No No Checksum Button
Vauxhall Zafira 2.0 16v Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Zafira 2.0 16v Turbo Bosch ME1.5.5 K-Line Yes Yes Yes
Vauxhall Zafira 2.0 16v Bosch ME7.6.H4 K-Line Yes Yes Yes
Vauxhall Zafira 2.0i Bosch ME7.6.2 CAN Yes Yes Yes
Vauxhall Zafira 2.0 TD Bosch EDC15M K-Line No No Checksum Button
Vauxhall Zafira 1.9 16V CDTI Bosch EDC16C9 CAN Yes Yes Yes
Vauxhall Zafira 1.9 16V CDTI Bosch EDC16C39 CAN Yes Yes Yes
Vauxhall Zafira 1.7 16V CDTI 110hp 2010 on Denso AX36 CAN Yes Yes Yes
Vauxhall Zafira 1.7 16V CDTI 125hp 2010 on Denso AX36 CAN Yes Yes Yes
Vauxhall Zafira 2.0 16V CDTI Bosch PSG16 CAN Yes Yes Yes
Vauxhall Zafira 2.2 16V CDTI Bosch PSG16 CAN Yes Yes Yes
Volkswagen Bora 1.4L Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Bora 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Bora 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Bora 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Bora 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Bora 2.3 V5 Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Bora 1.8L Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Bora 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Caddy 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Volkswagen Caddy 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Caddy 1.9 SDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Caddy 2.0 SDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Caddy 1.9 SDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Caddy 2.0 SDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Caddy 1.9 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Caddy 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Corrado VR6 Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Crafter 2.5 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Crafter 2.5 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Crafter 2.5 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Crafter 2.5 TDI CR Bosch EDC16CP34-4.4 CAN Yes Yes Yes
Volkswagen Crafter 2.7 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Crafter 3.0 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Crafter 2.5L Bosch ME7.1.1 CAN Yes Yes Yes
Volkswagen Eos 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Eos 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Eos 2.0 TDI PD Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Eos 2.0 TDI PD Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Eos 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Volkswagen Eos ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Eos ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Eos ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Eos ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Golf 1.4L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Golf 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Golf 1.4 TSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Golf 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Volkswagen Golf 1.9 SDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Golf 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Golf 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Golf 1.9 TDI PD Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Golf 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Golf 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Golf 2.0 TDI PD Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Golf 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Golf 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Golf 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Golf 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Golf 2.0L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Golf 2.0L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Golf 2.0L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Golf 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Golf 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Volkswagen Golf 2.3 V5 Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Golf 2.8L 12v Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Golf 2.8L 24v Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Golf 3.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Golf 3.2L Bosch ME7.1.1 CAN Yes Yes Yes
Volkswagen Golf 1.8L Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Golf VR6 Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Golf 2.0L Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Golf 2.3L Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Golf 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Golf 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Volkswagen Golf ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Golf ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Golf ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Golf ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Golf 2.0 TFSI Bosch MED17.5.2 CAN Yes Yes Yes
Volkswagen Jetta 1.4L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Jetta 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Jetta 1.4 TSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Jetta 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Volkswagen Jetta 1.9 SDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Jetta 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Jetta 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Jetta 1.9 TDI PD Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Jetta 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Jetta 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Jetta 2.0 TDI PD Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Jetta 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Jetta 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Jetta 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Jetta 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Jetta 2.0L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Jetta 2.0L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Jetta 2.0L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Jetta 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Jetta 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Volkswagen Jetta 2.3 V5 Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Jetta 2.8L 12v Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Jetta 2.8L 24v Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Jetta 3.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Jetta 3.2L Bosch ME7.1.1 CAN Yes Yes Yes
Volkswagen Jetta 1.8L Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Jetta VR6 Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Jetta 2.0L Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Jetta 2.3L Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Jetta 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Jetta 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Volkswagen Jetta ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Jetta ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Jetta ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Jetta ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Jetta 2.0 TFSI Bosch MED17.5.2 CAN Yes Yes Yes
Volkswagen LT35 2.5 TDI Bosch EDC15VM+ K-Line Yes Yes Checksum Button
Volkswagen Lupo 1.2 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Lupo 1.4 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen New Beetle 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 2.0L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 2.0L Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 2.0L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 2.3 V5 Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 2.5L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 2.9L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 3.2L RSi Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen New Beetle 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen New Beetle 2.0L Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Passat 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Volkswagen Passat 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Passat 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Passat 1.9 TDI PD Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Passat 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Passat 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Passat 2.0 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Passat 3.0 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Volkswagen Passat 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Passat 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Passat 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Passat 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Passat 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Volkswagen Passat 2.3 V5 Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Passat 2.8L V6 Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Passat 4.0L W8 Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Passat 3.6L V6 FSI Bosch MED9.1 CAN Yes Yes Checksum Button
Volkswagen Passat 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen Passat 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Volkswagen Passat ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Passat ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Passat ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Passat ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Phaeton 3.0 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Volkswagen Phaeton 3.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Phaeton 4.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Phaeton 5.0 TDI V10 Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Phaeton 5.0 TDI V10 Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Phaeton 5.0 TDI V10 Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Phaeton 5.0 TDI V10 Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Phaeton ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Phaeton ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Phaeton ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Phaeton ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Polo 1.4 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Polo 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Volkswagen Polo 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Polo 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Polo 1.9 SDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Polo 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Polo 1.4 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Polo 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Polo ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Polo ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Polo ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Polo ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Rabbit 1.4L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 1.9 SDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Rabbit 1.9 TDI PD Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Rabbit 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Rabbit 2.0 TDI PD Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Rabbit 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Rabbit 1.8L Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 2.0L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 2.0L Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 2.0L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Rabbit 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Volkswagen Rabbit 2.3 V5 Bosch ME7.1 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 2.9L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 2.8L 12v Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 2.8L 24v Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Rabbit 3.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Scirocco 1.4 TSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Scirocco 2.0 TFSI Turbo Bosch MED9.1 CAN Yes Yes Yes
Volkswagen Scirocco ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Scirocco ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Scirocco ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Scirocco ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Sharan 1.9 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Sharan 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Sharan 2.0 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Sharan 2.0 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen Sharan 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Sharan 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Sharan 1.8T Bosch M5.92 K-Line No Yes Checksum Button
Volkswagen T4 Bus 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen T5 Bus 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen T5 Bus 1.9 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen T5 Bus 1.9 TDI Bosch EDC16U31 K-Line/CAN Yes Yes Yes
Volkswagen T5 Bus 2.5 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen T5 Bus 2.5 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen T5 Bus 2.5 TDI Bosch EDC16U31-3.1 K-Line/CAN Yes Yes Yes
Volkswagen T5 Bus 2.5 TDI CR Bosch EDC16CP34-4.4 CAN Yes Yes Yes
Volkswagen Tiguan 1.4 TSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Tiguan 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Volkswagen Tiguan 1.9 TDI PD Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Tiguan 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Tiguan 2.0 TDI PD Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Tiguan 2.0 TFSI Bosch MED9.1 CAN Yes Yes Yes
Volkswagen Tiguan ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Tiguan ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Tiguan ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Tiguan ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Touran 1.6 TDI Siemens Simos Pcr2.x Can Yes Yes Yes
Volkswagen Touran 1.9 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Touran 1.9 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Touran 2.0 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Touran 2.0 TDI Bosch EDC16U34 K-Line/CAN Yes Yes Yes
Volkswagen Touran 1.6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Touran 1.8 Turbo Bosch ME7.5 K-Line Yes Yes Checksum Button
Volkswagen Touran 2.0 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Touran 2.0 TDI Siemens PPD 1.X K-Line/CAN Yes Yes Yes
Volkswagen Touran ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Touran ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Touran ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Touran ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Touareg 2.5 TDI Bosch EDC16U1 K-Line/CAN Yes Yes Yes
Volkswagen Touareg 3.0 TDI Bosch EDC16CP K-Line/CAN Yes Yes Yes
Volkswagen Touareg 3.2L Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Touareg 3.6L V6 FSI Bosch MED9.5.10 K-Line/CAN Yes Yes Checksum Button
Volkswagen Touareg 4.2L V8 Bosch ME7.1.1 K-Line Yes Yes Checksum Button
Volkswagen Touareg 5.0 TDI V10 Bosch EDC16U1 K-Line/CAN ECU 1 Yes Yes Yes
Volkswagen Touareg 5.0 TDI V10 Bosch EDC16U1 K-Line/CAN ECU 2 Yes Yes Yes
Volkswagen Touareg 5.0 TDI V10 Bosch EDC16U31 K-Line/CAN ECU 1 Yes Yes Yes
Volkswagen Touareg 5.0 TDI V10 Bosch EDC16U31 K-Line/CAN ECU 2 Yes Yes Yes
Volkswagen Touareg ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Touareg ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Vento ALL TFSI Bosch MED17 X CAN Yes Yes Yes
Volkswagen Vento ALL TFSI Bosch MED17 X UDS Yes Yes Yes
Volkswagen Vento ALL TDI Bosch EDC17 X CAN Yes Yes Yes
Volkswagen Vento ALL TDI Bosch EDC17 X UDS Yes Yes Yes
Volkswagen Marine TDI 100-5 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Marine TDI 120-5 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Marine TDI 150-5 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volkswagen Marine TDI 165-5 2.5 TDI Bosch EDC15 K-Line Yes Yes Checksum Button
Volvo C30 2.4 D (D5) Bosch EDC16C31 K-Line Yes Yes Yes
Volvo C70 2.4 D (D5) Bosch EDC16C11-4 K-Line Yes Yes Yes
Volvo C70 2.4 D (D5) Bosch EDC15C11-4 CAN 250k Yes Yes Yes
Volvo C70 2.4 D (D5) Bosch EDC16C31 K-Line Yes Yes Yes
Volvo C70 2.0T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo C70 2.3T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo C70 2.5T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo S40 1.9 CDI Bosch EDC15C3 K-Line Yes Yes Checksum Button
Volvo S40 2.4 D (D5) Bosch EDC16C31 K-Line Yes Yes Yes
Volvo S60 2.4 D (D5) Bosch EDC16C11-4 K-Line Yes Yes Yes
Volvo S60 2.4 D (D5) Bosch EDC15C11-4 CAN 250k Yes Yes Yes
Volvo S60 2.4 D (D5) Bosch EDC16C31 K-Line Yes Yes Yes
Volvo S60 2.0T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo S60 2.3T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo S60 2.4T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo S60 2.5T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo S80 2.4 D (D5) Bosch EDC16C11-4 K-Line Yes Yes Yes
Volvo S80 2.4 D (D5) Bosch EDC15C11-4 CAN 250k Yes Yes Yes
Volvo S80 2.4 D (D5) Bosch EDC16C31 K-Line Yes Yes Yes
Volvo S80 2.0T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo S80 2.4T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo S80 2.5T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo S80 2.8T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo S80 3.0T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo V40 1.9 CDI Bosch EDC15C3 K-Line Yes Yes Checksum Button
Volvo V50 2.4 D (D5) Bosch EDC16C31 K-Line Yes Yes Yes
Volvo V70 2.4 D (D5) Bosch EDC16C11-4 K-Line Yes Yes Yes
Volvo V70 2.4 D (D5) Bosch EDC15C11-4 CAN 250k Yes Yes Yes
Volvo V70 2.4 D (D5) Bosch EDC16C31 K-Line Yes Yes Yes
Volvo V70 2.0T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo V70 2.3T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo V70 2.4T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo V70 2.5T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo XC70 2.4 D (D5) Bosch EDC16C11-4 K-Line Yes Yes Yes
Volvo XC70 2.4 D (D5) Bosch EDC15C11-4 CAN 250k Yes Yes Yes
Volvo XC70 2.4 D (D5) Bosch EDC16C31 K-Line Yes Yes Yes
Volvo XC70 2.4T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo XC70 2.5T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Volvo XC90 2.4 D (D5) Bosch EDC16C11-4 K-Line Yes Yes Yes
Volvo XC90 2.4 D (D5) Bosch EDC15C11-4 CAN 250k Yes Yes Yes
Volvo XC90 2.4 D (D5) Bosch EDC16C31 K-Line Yes Yes Yes
Volvo XC90 2.5T Bosch ME7.0/01 CAN 250k/500k Yes Yes Yes
Posted by: OBDexpress.co.uk at
06:45 AM
| No Comments
| Add Comment
Post contains 21088 words, total size 146 kb.
July 15, 2017
This user
1.VPECKER EASYDIAG India software Running Environment
Hardware Environment:
Windows laptop, PC or PAD
CPU speed: more than 1.0G Hz
Memory: more than 1GB
Disk: more than 32 GB
Communication port: Wi-Fi or Bluetooth
Software Environment:
Windows XP, Windows 7, Windows 8, Windows 10
2. VPECKER India Software Installation
2.1 Client Downloading
Access to website:http://www.idutex.com, and then download the file "VPECKER-IN-SETUPVx.xxâ€
2.2 ClientSetup
Unzip VPECKER-IN-SETUPVx.xx and run setup.exe:
Please click "Installâ€.
VpeckerIndia diagnostic service system installs successfully.
VPECKER India SoftwareActivation
At first, please keep network working. Run VpeckerIndia APP, then click "Online Store†to get applications.
Please wait ...
Please click "Online Storeâ€.
Please enter
Please
If the product is not activated, please click "Yesâ€.
Please input your information, the Email address and country are required, and then click "Activateâ€.
Note:
Your email address must be real in order to get the activated link and the further better service from the manufacturer.The software update reminder and the new product release information will be sent to your email.
If you do not receive the activation email, please add"service@IDUTEX.com" to the white list of your mailbox and try the activation process again.
Company name: company name must be filled in and the length is within 250 characters.
Country: please
Please click the link to get the confirmation from the manufacturer.
Software Downloads
After the activation, please
Please, click "Login†to download the software.
More tech support please
Posted by: OBDexpress.co.uk at
02:44 AM
| No Comments
| Add Comment
Post contains 293 words, total size 13 kb.
This user munualabout where to downloadVPECKER EASYDIAG Indiasoftware and how toSoftware Activation ,install.
1.VPECKER EASYDIAG India software Running Environment
Hardware Environment:
Windows laptop, PC or PAD
CPU speed: more than 1.0G Hz
Memory: more than 1GB
Disk: more than 32 GB
Communication port: Wi-Fi or Bluetooth
Software Environment:
Windows XP, Windows 7, Windows 8, Windows 10
2. VPECKER India Software Installation
2.1 Client Downloading
Access to website:http://www.idutex.com, and then download the file "VPECKER-IN-SETUPVx.xxâ€
2.2 ClientSetup
Unzip VPECKER-IN-SETUPVx.xx and run setup.exe:
Pleaseclick "Nextâ€.
Pleaseclick "Nextâ€.
Please click "Installâ€.
VpeckerIndia diagnostic service system installs successfully.
VPECKER India SoftwareActivation
At first, please keep network working. Run VpeckerIndia APP, then click "Online Store†to get applications.
Please wait ...
Please click "Online Storeâ€.
Please enter theS/N numberand password get from the envelope, and then click "Loginâ€.
Please clich"Login"
If the product is not activated, please click "Yesâ€.
Please input your information, the Email address and country are required, and then click "Activateâ€.
Note:
Your email address must be real in order to get the activated link and the further better service from the manufacturer.The software update reminder and the new product release information will be sent to your email.
If you do not receive the activation email, please add"service@IDUTEX.com" to the white list of your mailbox and try the activation process again.
Company name: company name must be filled in and the length is within 250 characters.
Country: please choice your country in the list.
Please click the link to get the confirmation from the manufacturer.
Software Downloads
After the activation, please login the online store again, and get the APPs upgrade.
Please, click "Login†to download the software.
More tech support please download :VPECKERIndia User maunal
Posted by: OBDexpress.co.uk at
02:44 AM
| No Comments
| Add Comment
Post contains 289 words, total size 10 kb.
July 12, 2017
This is for your
FCar F502software version: 5.0
Part 2: How to update & install FCar F502 software
To install FCar F502software, you will need to have a mini-USB cable (NOT included
- Hold scanner’s "Enter†key and connect USB cable to your Windows PC (Mac is not supported), and then release "Enter†key. The scanner will go into Update Mode screen.
- Install USB VCOM driver (Only need
atfirsttime , see next USB VCOM driver installation guide) - Download the software
fromtopof this page, extract the zip file (ie. FcarReader_502_20150806.zip) into a folder. ie. d:\temp\FcarReader_502_20150806, run file named FcarReader_502.exe. Select COM number. (You will find the COM number on step 2, or you will be found under Control Panel–>Device Manager). - Start Update
- Press and Hold scanner’s "Enter†key and connect USB cable to your Windows 10, and then release "Enter†key.
Thescanerwill go into Update Mode screen. - Windows 10 will search driver and install automatically (first time only)
- Download the software fromtopof this page, extract the zip file (ie. FcarReader_502_20170508.zip) into a folder. ie. d:\temp\FcarReader_502_20170508, run file named FcarReader_502.exe.
- Select COM number. (You will be found under Control Panel–>Device Manager).
- Click Start Upgrade
-
Wholeprocess will take about 2-3 minutes, and it will auto restart. - Select USB Serial Device (COM3)
Part 3: How to installFCar F502USB VCOM driver on Win XP/Vista/7/8/10
For users with Windows XP/Vista:
Find file:
For users with Windows 7:
1)Click Windows Start menu–>Control Panel–>Device Manager
2)Right lick on "F50x USB VCom Port (COM4)†under Ports (COM & LPT)
3)Select Update Driver and Browse my computer for driver software
4)
For users with Windows 8:
Under Windows 7 64bits, Windows 8 or Windows 10, you have
How To Disable Driver Signature Enforcement In Windows 8/8.1 And Windows 10
- Find PC Settings from the start menu or apps list >> select Update and Recovery >> click Recovery.
- Under Advanced Startup, click on Restart Now.
- Your PC will do a kind of reboot and go to a blue Choose an option screen. Click on Troubleshoot (refresh or reset your PC or use advanced tools) >> Advanced Options >> Startup Settings (change windows startup behaviour) >> Restart.
- Your PC will now restart and go to yet another blue screen with 10 options. Press 7 or F7 on your keyboard to select Disable driver signature enforcement.
- Your computer will auto restart again and then you can now proceed with the installation of FCAR F502 USB VCOM driver for Windows 7/8/8.1/10.
When the Windows driver
Part
Now, you have finish FCar F502 driver software update. And it’s ready for use.
" data-blogger-escaped-style="border: 0px; font-family: inherit; font-size: inherit; font-stretch: inherit; font-style: inherit; font-variant: inherit; font-weight: inherit; height: auto; line-height: inherit; margin: 0px; max-width: 100%; padding: 0px; vertical-align: baseline;" data-orig-src="http://blog.obdexpress.co.uk/wp-content/uploads/2017/07/FCar-F502-truck-reader-how-to-use-8-600x300.gif" height="300" src="https://images-blogger-opensocial.googleusercontent.com/gadgets/proxy?url=http%3A%2F%2Fblog.obdexpress.co.uk%2Fwp-content%2Fuploads%2F2017%2F07%2FFCar-F502-truck-reader-how-to-use-8-600x300.gif&container=blogger&gadget=a&rewriteMime=image%2F*" width="600" />
This is all for how to
Posted by: OBDexpress.co.uk at
02:04 AM
| No Comments
| Add Comment
Post contains 530 words, total size 57 kb.
July 10, 2017
This is for your information: Looking forMPPS V21.
MPPS V21 clone in
MPPS V21 software, car list download, review:
There are only 2 variants for the moment ORIGINAL and CLONE.
Clone you can buy for 100EU or less and ORI for 2500EU.
Thanks for comments:
Read written FLESH + MPC + EEPROMfiat
There are few tools that read-write EEPROM
OBD-flash reading 3min 20 sec., 45 sec-writing.
MPC and EEPROM read OBD-20 seconds, 20 seconds writing (
testededc16u1 from T5 2007 1.9tdi AXB 77kw.
make sure you remove the fan plug from fan controller when writing on this cars. when flash is erased the fan will work on max
Ems3132Bootmode. Read ok. Write not ok.
It erases the flash and cannot write.
Revived by k-tag.
MPPS V18
If you want to flashPSG16 In Astra
Vectra C, Signum etc – through OBD port.
It is not so bad for a 50-60 euro tool !!!
Jetta 2,0 16v TSi 200cv – MED17.5.2 Tprot10
Read in Boot = OK
made OBD unlock and CKS by MPPS, write boot = OK
siemens
BRD: R4 2.0l PPD1.3 G 9973
read ..write
it’s working.both can and kline. tested onbmw edc16c31,edc15v/,edc16u1
Marelli 6F3or others…
Audi a4 edc17cp14..read… write
HW: 03L 906 022 B
R4 2,0L EDC H01 4375
NISSAN Q. EDC16CP33(4A44383842) R/W OBD = OK (CRC-OK).
Magneti Marelli 6f3, 6JF, 8F2, 8F3in
Alfa Roméo Giulietta 2L 170cv EDC16 C39(can line): read/write by
Fiat Punto
edc16C39 and mjd8work fine on good V18….without recovery……..
Writeedc16C39failure with
Recovery of
Readingpsg16
Used MPPS V18 to Read Flash fromVauxhall Astra 1.7 CDTI 2012 Denso ECUvery quick with no issues.
And alsoEDC17 CP20 on Volkswagen Passat 2.0 TDI 2009took about 3
Suzuki SX4 DDIS 1.9L 120hp, Bosch EDC16C39 2008,can & kline, read & write by obd ok.
mpps= read= unlok file = write unlok file = not boot = kess obd2 = open file unlok = write obd2 kess= ok
Magneti Marelli 6f3, Reading at the BDM works very well!
Opel Corsa 2004 1.3cdti
tested todayedc16u31 on mk5
Posted by: OBDexpress.co.uk at
08:44 AM
| No Comments
| Add Comment
Post contains 581 words, total size 46 kb.
July 06, 2017
so many kind of ktagecuversion ,What is the difference between them?
Ktag v6.070 vs ktag ktm100 v7.003 vs K-Tag fw v7.020 here:
|
Product |
Ktag v7.020(SE135) |
K-tag v7.020(SE135-B) |
||
|
Image |
|
|
|
|
|
Price |
$69 |
$315 |
$425 |
$199 |
|
Firmware version |
V6.070 |
V7.003 |
V7.020 |
V7.020 |
|
Software version |
Ksuite V2.13 |
KTM100 V2.13 |
Ksuite V2.23 |
Ksuite V2.23 |
|
Token charging |
Through PC programming |
With one renew button |
NO TOKENS LIMITATION |
NO TOKENS LIMITATION |
|
Language |
English/ Italian/ German/ French/ Portuguese/ Spanish |
English/ Italian/ Portuguese |
English/ Italian/ Portuguese/ French/ Dutch/ Spanish |
English/ Italian/ Portuguese/ French/ Dutch/ Spanish |
|
ECU wiring diagram |
Displayed in pictures |
Displayed in pictures |
Displayed in words |
Displayed in words |
|
BMW F chassis petrol |
NO |
YES |
Unknown |
Unknown |
|
Mercedes-Benz W222 |
NO |
YES |
Unknown |
Unknown |
|
Mercedes-Benz 276ECU |
NO |
NO |
YES |
YES |
|
Toyota76FXXX |
NO |
NO |
YES |
YES |
|
PSA 17.4.4 |
NO |
NO |
YES |
YES |
|
VW 17.5.5 (1766) |
NO |
NO |
YES |
YES |
|
Ford E83 |
NO |
NO |
YES |
YES |
|
Car list/ ECU support |
All supports Cars, Motorcycles,Tractors, TrucksECU programming |
|||
|
Less (download:k-tag-ksuit-car-list) |
More (download:ktm100-ktag-car-list) |
Most (add: 100+ ECU types download:ktag 7.020 car list) |
Most (add: 100+ ECU types) download:ktag 7.020 car list |
|
|
Protocols |
over 95% (BDM MOTOROLA MPC5xx) |
More than ktag ksuite (BDM MOTOROLA MPC5xx) |
BDM MOTOROLA MPC5xx |
BDM MOTOROLA MPC5xx |
|
More info |
No |
No |
Add New File type (FENDT/JCB/VALTRA TRACTOR BOSCH EDC17CV41 SISU ENGINE CAN |
Add New File type (FENDT/JCB/VALTRA TRACTOR BOSCH EDC17CV41 SISU ENGINE CAN |
2017 new Ktag firmware v7.020 adds 100+ ECU types, compared with old ktag programmers.
BDM 68K (CAT ADEM III, etc)
BDM HC12 (Continental Siemens VDO, etc)
BDM HC16 (DENSO 21175, etc)
BDM MPC5XX (BOSCH EDC16/16+, BOSCH EDC7, BOSCH ME9/9+, etc )
BOOTLOADER M32R (DENSO 21175, etc)
BOOTLOADER MITSUBISHI (MITSUBISHI 21175, MITSUBISHI E6T, MITSUBISHI E2T, etc)
BOOTLOADER ST10FXXX (BOSCH M7.4.4, BOSCH M7.9.7, BOSCH ME7.1.1, BOSCH ME7.4.4, BOSCH ME7.4.5, BOSCH ME7.9.10, etc)
BOOTLOADER TRICORE (BOSCH EDC17, BOSCH ME17, CONTINENTAL SID208, SIEMENS EMS2204, SIEMENS EMS3110, etc)
JTAG MPC5XXX (CONTINENTAL CM2150E, MARELLI 8DF, DELPHI DCM3.5, etc)
JTAG RENESAS (DELPHI DCM3.4, DELPHI DCM3.7, DENSO 32920, DENSO RA6, HITACHI A56, HITACHI MEC, etc)
NBD NEC 76F00XX (DENSO 175822 TOYOTA, DENSO 275036 TOYOTA, etc)
KTAG work only for bdm, j-tag, boot.So sometimes, you are used to use it with other programmers like Mpps cable, kess v2, fgtech…
Galletto 4 work with truck, including Benz truck, read and write ECU via both BDM and OBD; KESS not works with truck, read and write ECU via only OBD, not BDM.
KESS V2is aECU programming toolthat is perfect for OBD use, while KTag is perfect for Jtag, BDM and all the Boot application (tricore and ST10).
With KESS V2 you programming directly through the OBD port of the vehicle, while with Ktag (Ktag 2.13) you need to take apart the ECU and open it, after you can make the read/write operation.
Many ECU has the advantage that can be read and write from OBD port (so KESS V2 is perfect), but there are lot ECU that need to disassemble from the car and open and this is the case for all the ECU that need to be programmed with Jtag, BDM and Boot protocols, so KTAG is needed.
Because non of China tool will cover all cars good and if you buy clone tools, buy all (galletto+kess+ktag) from them, that you will cover more cars, or better to buy a good original tool if you will do the work as a pro, all depends want you will do.
Posted by: OBDexpress.co.uk at
03:25 AM
| No Comments
| Add Comment
Post contains 590 words, total size 99 kb.
July 05, 2017
Kess V2Ksuite2.35 is tested successfully and released athttp://www.obdexpress.co.uk/producttags/kess-v2.htmlwith new cars & protocols available:
KESSv2 v2.35 New Cars/Protocols：
Kess v2 2.35 adds new cars and protocols.
Now, it is the one working with the MOST cars and protocols.
- Kess v2 2.35 Vehicle List (Newly added)
Car
Prt573 | Ford Continental EMS24XX MY2015
Prt582 | PSA Bosch ME7.4.7
Prt584 | GM / Opel / Chevrolet Delco E38
Prt585 | Ssangyong Delphi DCM6.2
Prt587 | Ford Bosch EDC17CP05
Prt590 | Porsche Continental SDI10.2
Prt595 | VAG Delphi DCM6.2V
Prt596 | Iveco Bosch EDC17C69
DSG Gearbox
Prt577 | DSG DL501 CAN
Truck
Prt588 | Cummins Hyundai Truck Continental CM2350A CAN
Prt591 | Cummins Autosan Truck Continental CM2150E CAN
Prt592 |Cummins PeterbiltTruck Motorola CM875 CAN
Prt594 | Cummins BCI Truck Motorola CM850 CAN
Prt598 | Cummins International Truck Motorola CM876 CAN
Prt601 | Cummins Alexander-Dennis Truck Motorola CM850 CAN
Prt603 | Cummins Freightliner Truck Recon CM2150E CAN
Tractor
Prt586 | Cummins GVM Tractor Motorola CM850 CAN
Prt597 | CumminsHuddingTractor Continental CM2250 CAN
Prt599 | Cummins Hagie Tractor Motorola CM850 CAN
Prt600 | Cummins Crary Tractor Motorola CM850 CAN
Prt602 | Cummins John Deere Tractor 2350A
- Kess v2 2.35 Protocol List (Newly added)
Ford Continental EMS24XX MY2015
KESSv2 – Prt 573
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300KCAN
| Model | Model Name | Engine | KW | HP | Fuel | MY | ECU | ECU Version |
| Ford | Mustang | 3.7 Ti-VCT V6 6AT | 224 | 300 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang | 3.7 Ti-VCT V6 6MT | 224 | 300 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang | 5.0 Ti-VCT V8 6AT | 310 | 416 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang | 5.0 Ti-VCT V8 6AT | 320 | 429 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang | 5.0 Ti-VCT V8 6MT | 320 | 429 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang | 5.0 Ti-VCT V8 6MT | 310 | 416 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang Convertible | 3.7 Ti-VCT V6 6AT | 224 | 300 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang Convertible | 3.7 Ti-VCT V6 6MT | 224 | 300 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang Convertible | 5.0 Ti-VCT V8 6AT | 320 | 429 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang Convertible | 5.0 Ti-VCT V8 6AT | 310 | 416 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang Convertible | 5.0 Ti-VCT V8 6MT | 320 | 429 | Petrol | 2015 | Continental | EMS24xx |
| Ford | Mustang Convertible | 5.0 Ti-VCT V8 6MT | 310 | 416 | Petrol | 2015 | Continental | EMS24xx |
PSA Bosch ME7.4.7
KESSv2 – Prt 582
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300KCAN
| Model | Model Name | Engine | Engine Code | KW | HP | Fuel | MY | ECU | ECU Version |
| Citroen | C5 | 3.0 V6 24v | XFV | 155 | 208 | Petrol | 2004 | Bosch | ME7.4.7 |
| Citroen | C6 | 3.0 V6 24v | XFV | 155 | 208 | Petrol | 2005 | Bosch | ME7.4.7 |
| Peugeot | 407 | 3.0 V6 24v | XFV | 155 | 208 | Petrol | 2004 | Bosch | ME7.4.7 |
| Peugeot | 607 | 3.0 V6 24v | XFV | 155 | 208 | Petrol | 2004 | Bosch | ME7.4.7 |
GM / Opel / Chevrolet Delco E38
KESSv2 – Prt 584
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300KCAN
| Model | Model Name | Engine | Engine Code | KW | HP | Fuel | MY | ECU | ECU Version |
| Cadillac | Escalade | 6.2 V8 6AT | 301 | 565 | Petrol | 2007 | Ac Delco | E38 | |
| Chevrolet | Corvette | 6.0 V8 | LS2 | 300 | 402 | Petrol | 2006 | Ac Delco | E38 |
| Chevrolet | Corvette | 6.2 V8 | LS3 | 321 | 430 | Petrol | 2008 | Ac Delco | E38 |
| Chevrolet | Express | 4.8 V8 | 194 | 260 | Petrol | 2010 | Ac Delco | E38 | |
| Chevrolet | Express | 5.3 V8 | 239 | 320 | Petrol | 2008 | Ac Delco | E38 | |
| Chevrolet | Express | 6.0 V8 | 255 | 342 | Petrol | 2010 | Ac Delco | E38 | |
| Chevrolet | Impala | 3.5 V6 | LZ4 | 167 | 565 | Petrol | 2006 | Ac Delco | E38 |
| Chevrolet | Impala | 3.9 V6 | LZ9 | 180 | 565 | Petrol | 2006 | Ac Delco | E38 |
| Chevrolet | Malibu | 3.5 V6 6AT | LZ4 | 157 | 217 | Petrol | 2007 | Ac Delco | E38 |
| Chevrolet | Monte Carlo | 3.5 V6 6AT | LZ4 | 157 | 211 | Petrol | 2006 | Ac Delco | E38 |
| Chevrolet | Monte Carlo | 3.9 V6 | LZ9 | 180 | 565 | Petrol | 2006 | Ac Delco | E38 |
| Chevrolet | Silverado | 4.8 V8 | 220 | 295 | Petrol | 2007 | Ac Delco | E38 | |
| Chevrolet | Silverado | 4.8 V8 | 225 | 302 | Petrol | 2010 | Ac Delco | E38 | |
| Chevrolet | Silverado | 5.3 V8 | 235 | 315 | Petrol | 2007 | Ac Delco | E38 | |
| Chevrolet | Silverado | 6.0 V8 | 274 | 367 | Petrol | 2007 | Ac Delco | E38 | |
| Chevrolet | Silverado | 6.2 V8 | 301 | 404 | Petrol | 2009 | Ac Delco | E38 | |
| Chevrolet | SS | 6.2 V8 6AT | LS3 | 310 | 416 | Petrol | 2014 | Ac Delco | E38 |
| Chevrolet | Suburban | 5.3 V8 6AT | LY5 | 243 | 326 | Petrol | 2007 | Ac Delco | E38 |
| Chevrolet | Suburban | 6.0 V8 4AT | L76 | 262 | 351 | Petrol | 2007 | Ac Delco | E38 |
| Chevrolet | Tahoe | 4.8 V8 | LY2 | 220 | 295 | Petrol | 2007 | Ac Delco | E38 |
| Chevrolet | Tahoe | 5.3 V8 | LY5 | 235 | 315 | Petrol | 2007 | Ac Delco | E38 |
| Chevrolet | Tahoe | 6.2 V8 | 301 | 404 | Petrol | 2007 | Ac Delco | E38 | |
| GMC | Savana | 4.8 V8 | 194 | 260 | Petrol | 2010 | Ac Delco | E38 | |
| GMC | Savana | 5.3 V8 | 239 | 320 | Petrol | 2008 | Ac Delco | E38 | |
| GMC | Savana | 6.0 V8 | 255 | 342 | Petrol | 2010 | Ac Delco | E38 | |
| GMC | Sierra | 4.8 V8 | 220 | 295 | Petrol | 2007 | Ac Delco | E38 | |
| GMC | Sierra | 4.8 V8 | 225 | 302 | Petrol | 2010 | Ac Delco | E38 | |
| GMC | Sierra | 5.3 V8 | 235 | 315 | Petrol | 2007 | Ac Delco | E38 | |
| GMC | Sierra | 6.0 V8 | 274 | 367 | Petrol | 2007 | Ac Delco | E38 | |
| GMC | Sierra | 6.2 V8 | 301 | 404 | Petrol | 2009 | Ac Delco | E38 | |
| GMC | Yukon | 4.8 V8 | LY2 | 220 | 295 | Petrol | 2007 | Ac Delco | E38 |
| GMC | Yukon | 5.3 V8 | LY5 | 235 | 315 | Petrol | 2007 | Ac Delco | E38 |
| GMC | Yukon | 6.2 V8 | 301 | 404 | Petrol | 2007 | Ac Delco | E38 | |
| Holden | Commodore | 6.0 V8 6AT | L77 | 260 | 349 | Petrol | 2013 | Ac Delco | E38 |
| Holden | Commodore | 6.0 V8 6MT | L77 | 270 | 362 | Petrol | 2013 | Ac Delco | E38 |
| Holden | Commodore | 6.2 V8 6MT | LS3 | 304 | 408 | Petrol | 2015 | Ac Delco | E38 |
| Pontiac | G6 | 3.5 V6 6AT | LZ4 | 157 | 211 | Petrol | 2007 | Ac Delco | E38 |
| Pontiac | G8 | 6.0 V8 6AT | L76 | 270 | 362 | Petrol | 2009 | Ac Delco | E38 |
| Pontiac | G8 | 6.2 V8 6MT | LS3 | 304 | 408 | Petrol | 2009 | Ac Delco | E38 |
| Saturn | Aura | 3.5 V6 6AT | LZ4 | 157 | 211 | Petrol | 2007 | Ac Delco | E38 |
| Saturn | Vue | 3.5 V6 6AT | LZ4 | 157 | 211 | Petrol | 2008 | Ac Delco | E38 |
Ssangyong Delphi DCM6.2
KESSv2 – Prt 585
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300KCAN
| Model | Model Name | Engine | Engine Code | KW | HP | Fuel | MY | ECU | ECU Version |
| Ssangyong | Actyon | 2.2 e-XDi | 131 | 176 | Diesel | 2016 | Delphi | DCM6.2AP | |
| Ssangyong | Actyon Sports | 2.2 e-XDi | 131 | 176 | Diesel | 2016 | Delphi | DCM6.2AP | |
| Ssangyong | Korando | 2.2 e-XDi | D22DTF | 131 | 176 | Diesel | 2015 | Delphi | DCM6.2AP |
| Ssangyong | Rexton | 2.2 e-XDi | D22DTR | 131 | 176 | Diesel | 2015 | Delphi | DCM6.2AP |
Ford Bosch EDC17CP05
KESSv2 – Prt 587
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300KCAN
| Model | Model Name | Engine | KW | HP | Fuel | MY | ECU | ECU Version |
| Ford | F-250 Super Duty | 6.7 V8 Powerstroke | 298 | 400 | Diesel | 2011 | Bosch | EDC17CP05 |
| Ford | F-250 Super Duty | 6.7 V8 Powerstroke | 328 | 440 | Diesel | 2015 | Bosch | EDC17CP05 |
| Ford | F-350 Super Duty | 6.7 V8 Powerstroke | 298 | 400 | Diesel | 2011 | Bosch | EDC17CP05 |
| Ford | F-350 Super Duty | 6.7 V8 Powerstroke | 328 | 440 | Diesel | 2015 | Bosch | EDC17CP05 |
| Ford | F-450 Super Duty | 6.7 V8 Powerstroke | 298 | 400 | Diesel | 2011 | Bosch | EDC17CP05 |
| Ford | F-450 Super Duty | 6.7 V8 Powerstroke | 328 | 440 | Diesel | 2015 | Bosch | EDC17CP05 |
| Ford | F-550 Super Duty | 6.7 V8 Powerstroke | 298 | 400 | Diesel | 2011 | Bosch | EDC17CP05 |
| Ford | F-550 Super Duty | 6.7 V8 Powerstroke | 328 | 440 | Diesel | 2015 | Bosch | EDC17CP05 |
Porsche Continental SDI10.2
KESSv2 – Prt 590
– Read: Virtual reading
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300KCAN
| Model | Model Name | Engine | Engine Code | KW | HP | Fuel | MY | ECU | ECU Version |
| Porsche | Macan GTS | 3.0 V6 Turbo 7AT | MDC.NA | 265 | 355 | Petrol | 2015 | Continental | SDI10.2 |
| Porsche | Macan S | 3.0 V6 Turbo 7AT | MCT.MA | 250 | 335 | Petrol | 2014 | Continental | SDI10.2 |
VAG Delphi DCM6.2V
KESSv2 – Prt 595
– Read: Virtual reading
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300KCAN
| Model | Model Name | Engine | Engine Code | KW | HP | Fuel | MY | ECU | ECU Version |
| Audi | A1 | 1.4 TDI Ultra (90) | CUSB | 66 | 89 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A1 | 1.4 TDI Ultra (90) S-Tronic | CUSB | 66 | 89 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A1 | 1.6 TDI (115) | CXMA | 85 | 114 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A1 | 1.6 TDI (115) S-Tronic | CXMA | 85 | 114 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A1 Sportback | 1.4 TDI Ultra (90) | CUSB | 66 | 89 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A1 Sportback | 1.4 TDI Ultra (90) S-Tronic | CUSB | 66 | 89 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A1 Sportback | 1.6 TDI (115) | CXMA | 85 | 114 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A1 Sportback | 1.6 TDI (115) S-Tronic | CXMA | 85 | 114 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 | 1.6 TDI (110) Clean Diesel | CXXB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 | 1.6 TDI (110) Clean Diesel | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 | 1.6 TDI (110) Clean Diesel S-Tronic | CXXB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 | 1.6 TDI (110) Clean Diesel S-Tronic | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 | 1.6 TDI Ultra (110) | CXXB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 | 1.6 TDI Ultra (110) | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sedan | 1.6 TDI (110) Clean Diesel | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sedan | 1.6 TDI (110) Clean Diesel | CXXB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sedan | 1.6 TDI (110) Clean Diesel S-Tronic | CXXB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sedan | 1.6 TDI (110) Clean Diesel S-Tronic | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sedan | 1.6 TDI Ultra (110) | CXXB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sedan | 1.6 TDI Ultra (110) | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sportback | 1.6 TDI (110) Clean Diesel | CXXB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sportback | 1.6 TDI (110) Clean Diesel | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sportback | 1.6 TDI (110) Clean Diesel S-Tronic | CXXB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sportback | 1.6 TDI (110) Clean Diesel S-Tronic | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sportback | 1.6 TDI Ultra (110) | CXXB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | A3 Sportback | 1.6 TDI Ultra (110) | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Audi | Q2 | 1.6 TDI (115) | DDYA | 85 | 114 | Diesel | 2016 | Delphi | DCM6.2V |
| Audi | Q2 | 1.6 TDI (115) S-Tronic | DDYA | 85 | 114 | Diesel | 2016 | Delphi | DCM6.2V |
| Audi | Q2 | 2.0 TDI (150) Quattro S-Tronic | DCYA | 110 | 148 | Diesel | 2016 | Delphi | DCM6.2V |
| Seat | Ibiza | 1.4 TDI | CUTA | 77 | 103 | Diesel | 2015 | Delphi | DCM6.2V |
| Seat | Ibiza | 1.4 TDI | CUSA | 55 | 74 | Diesel | 2015 | Delphi | DCM6.2V |
| Seat | Ibiza | 1.4 TDI | CUSB | 66 | 89 | Diesel | 2015 | Delphi | DCM6.2V |
| Seat | Leon | 1.6 TDI | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Seat | Leon | 1.6 TDI | CXXA | 66 | 89 | Diesel | 2015 | Delphi | DCM6.2V |
| Seat | Leon | 1.6 TDI | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Seat | Toledo | 1.4 TDI | CUSB | 66 | 89 | Diesel | 2015 | Delphi | DCM6.2V |
| Seat | Toledo | 1.6 TDI | CXMA | 85 | 114 | Diesel | 2015 | Delphi | DCM6.2V |
| Skoda | Fabia | 1.4 TDI | CUTA | 77 | 103 | Diesel | 2014 | Delphi | DCM6.2V |
| Skoda | Fabia | 1.4 TDI | CUSB | 66 | 89 | Diesel | 2014 | Delphi | DCM6.2V |
| Skoda | Fabia | 1.4 TDI | CUSA | 55 | 74 | Diesel | 2015 | Delphi | DCM6.2V |
| Skoda | Octavia | 1.6 TDI | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Skoda | Octavia | 1.6 TDI | CXXA | 66 | 89 | Diesel | 2015 | Delphi | DCM6.2V |
| Skoda | Octavia | 1.6 TDI | CRKB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Skoda | Octavia | 1.6 TDI | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Skoda | Rapid | 1.4 TDI | CUSB | 66 | 89 | Diesel | 2015 | Delphi | DCM6.2V |
| Skoda | Rapid | 1.6 16v TDI | CXMA | 85 | 114 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | California | 2.0 16v TDI | CXGB | 75 | 101 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | California | 2.0 16v TDI | CXGA | 62 | 83 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | California | 2.0 16v TDI | CXEB | 150 | 201 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | California | 2.0 16v TDI | CXHA | 110 | 148 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | California | 2.0 16v TDI | CXFA | 110 | 148 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | California | 2.0 16v TDI | CXHB | 84 | 113 | Diesel | 2016 | Delphi | DCM6.2V |
| Volkswagen | Caravelle | 2.0 16v TDI | CXGB | 75 | 101 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Caravelle | 2.0 16v TDI | CXGA | 62 | 83 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Caravelle | 2.0 16v TDI | CXEB | 150 | 201 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Caravelle | 2.0 16v TDI | CXFA | 110 | 148 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Caravelle | 2.0 16v TDI | CXHA | 110 | 148 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Caravelle | 2.0 16v TDI | CXHB | 84 | 113 | Diesel | 2016 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI 4Motion 6MT | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI 4Motion 6MT | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI 4Motion 6MT | CRKB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI BlueMotion 5MT | CXXA | 66 | 89 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI BlueMotion 5MT | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI BlueMotion 5MT | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI BlueMotion 5MT | CRKB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI BlueMotion 7AT | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI BlueMotion 7AT | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI BlueMotion 7AT | CRKB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf | 1.6 TDI BlueMotion 7AT | DDYA | 85 | 114 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf | 2.0 TDI 4Motion 6MT | DCYA | 110 | 148 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf | 2.0 TDI BlueMotion 6AT | DCYA | 110 | 148 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf | 2.0 TDI BlueMotion 6MT | DCYA | 110 | 148 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf Alltrack | 1.6 TDI 4Motion 6MT | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf Alltrack | 1.6 TDI 4Motion 6MT | CRKB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf Alltrack | 2.0 TDI 4Motion 6MT | DCYA | 110 | 148 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf Sportsvan | 1.6 TDI BlueMotion 5MT | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf Sportsvan | 1.6 TDI BlueMotion 5MT | CXXA | 66 | 89 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf Sportsvan | 1.6 TDI BlueMotion 5MT | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf Sportsvan | 1.6 TDI BlueMotion 7AT | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf Sportsvan | 1.6 TDI BlueMotion 7AT | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf Sportsvan | 1.6 TDI BlueMotion 7AT | DDYA | 85 | 114 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf Sportsvan | 2.0 TDI BlueMotion 6AT | DCYA | 110 | 148 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf Sportsvan | 2.0 TDI BlueMotion 6MT | DCYA | 110 | 148 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI 4Motion 6MT | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI 4Motion 6MT | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI 4Motion 6MT | CRKB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI BlueMotion 5MT | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI BlueMotion 5MT | CXXA | 66 | 89 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI BlueMotion 5MT | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI BlueMotion 5MT | CRKB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI BlueMotion 7AT | CXXB | 81 | 109 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI BlueMotion 7AT | CRKB | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI BlueMotion 7AT | DBKA | 81 | 109 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 1.6 TDI BlueMotion 7AT | DDYA | 85 | 114 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 2.0 TDI 4Motion 6MT | DCYA | 110 | 148 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 2.0 TDI BlueMotion 6AT | DCYA | 110 | 148 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Golf Variant | 2.0 TDI BlueMotion 6MT | DCYA | 110 | 148 | Diesel | 2017 | Delphi | DCM6.2V |
| Volkswagen | Multivan | 2.0 16v TDI | CXGB | 75 | 101 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Multivan | 2.0 16v TDI | CXGA | 62 | 83 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Multivan | 2.0 16v TDI | CXEB | 150 | 201 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Multivan | 2.0 16v TDI | CXFA | 110 | 148 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Multivan | 2.0 16v TDI | CXHA | 110 | 148 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Multivan | 2.0 16v TDI | CXHB | 84 | 113 | Diesel | 2016 | Delphi | DCM6.2V |
| Volkswagen | Polo | 1.4 TDI | CUTA | 77 | 103 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Polo | 1.4 TDI | CUSA | 55 | 74 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Polo | 1.4 TDI | CUSB | 66 | 89 | Diesel | 2014 | Delphi | DCM6.2V |
| Volkswagen | Transporter | 2.0 16v TDI | CXGB | 75 | 101 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Transporter | 2.0 16v TDI | CXGA | 62 | 83 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Transporter | 2.0 16v TDI | CXHA | 110 | 148 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Transporter | 2.0 16v TDI | CXFA | 110 | 148 | Diesel | 2015 | Delphi | DCM6.2V |
| Volkswagen | Transporter | 2.0 16v TDI | CXHB | 84 | 113 | Diesel | 2016 | Delphi | DCM6.2V |
| Volkswagen | Transporter | 2.0 16v TDI | CXEB | 150 | 201 | Diesel | 2016 | Delphi | DCM6.2V |
Iveco Bosch EDC17C69
KESSv2 – Prt 596
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K208
| Model | Model Name | Engine | Engine Code | KW | HP | Fuel | MY | ECU | ECU Version |
| Iveco | Daily | 35C12 2.3L I4 | F1AGL411H | 85 | 114 | Diesel | 2016 | Bosch | EDC17C69 |
| Iveco | Daily | 35C14 2.3L I4 | F1AGL411J | 100 | 134 | Diesel | 2016 | Bosch | EDC17C69 |
| Iveco | Daily | 35C16 2.3L I4 | F1AGL411G | 110 | 148 | Diesel | 2016 | Bosch | EDC17C69 |
| Iveco | Daily | 35S12 2.3L I4 | F1AGL411G | 110 | 148 | Diesel | 2016 | Bosch | EDC17C69 |
| Iveco | Daily | 35S12 2.3L I4 | F1AGL411J | 100 | 134 | Diesel | 2016 | Bosch | EDC17C69 |
| Iveco | Daily | 35S12 2.3L I4 | F1AGL411H | 85 | 114 | Diesel | 2016 | Bosch | EDC17C69 |
DSG Gearbox
KESSv2 – Prt 577
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K265
| Model | Model Name | Engine | Engine Code | KW | HP | Fuel | MY | ECU | ECU Version |
| Audi | A4 | 3.0 TDI Quattro S-Tronic | CCWA | Diesel | 176 | 236 | 2009 | TCM | Temic |
| Audi | A5 | 3.0 TDI Quattro S-Tronic | CCWA | Diesel | 176 | 236 | 2009 | TCM | Temic |
| Audi | A5 | 2.0 TFSI Quattro S-Tronic | CDNC | Petrol | 155 | 208 | 2009 | TCM | Temic |
| Audi | A5 Cabriolet | 3.0 TDI Quattro S-Tronic | CCWA | Diesel | 176 | 236 | 2009 | TCM | Temic |
| Audi | A5 Cabriolet | 2.0 TFSI Quattro S-Tronic | CDNC | Petrol | 155 | 208 | 2009 | TCM | Temic |
| Audi | A5 Sportback | 3.0 TDI Quattro S-Tronic | CCWA | Diesel | 176 | 236 | 2009 | TCM | Temic |
| Audi | A5 Sportback | 2.0 TFSI Quattro S-Tronic | CDNC | Petrol | 155 | 208 | 2009 | TCM | Temic |
| Audi | A5 Sportback | 2.0 TFSI Quattro S-Tronic | CDNC | Petrol | 155 | 208 | 2011 | TCM | Temic |
| Audi | A6 | 3.0 TDI (245) Quattro S-Tronic | CDUD | Diesel | 180 | 241 | 2012 | TCM | Temic |
| Audi | A6 | 3.0 TFSI Quattro S-Tronic | CGWD | Petrol | 228 | 306 | 2013 | TCM | Temic |
| Audi | A6 Allroad | 3.0 TDI (245) Quattro S-Tronic | CDUD | Diesel | 180 | 241 | 2012 | TCM | Temic |
| Audi | A6 Allroad | 3.0 TFSI Quattro S-Tronic | CGWD | Petrol | 228 | 306 | 2012 | TCM | Temic |
| Audi | A7 | 3.0 TFSI Quattro S-Tronic | CGWD | Petrol | 228 | 306 | 2013 | TCM | Temic |
| Audi | A7 | 3.0 TFSI Quattro S-Tronic | CTUA | Petrol | 228 | 306 | 2013 | TCM | Temic |
| Audi | Q5 | 2.0 16v TDI | CNHA | Diesel | 140 | 188 | 2015 | TCM | Temic |
| Audi | Q5 | 2.0 16v TDI quattro | CNHA | Diesel | 140 | 188 | 2014 | TCM | Temic |
| Audi | Q5 | 2.0 16v TDI quattro S-Tronic | CAHA | Diesel | 125 | 168 | 2008 | TCM | Temic |
| Audi | Q5 | 2.0 16v TDI quattro S-Tronic | CGLB | Diesel | 125 | 168 | 2008 | TCM | Temic |
| Audi | Q5 | 2.0 16v TDI quattro S-Tronic | CGLC | Diesel | 130 | 174 | 2011 | TCM | Temic |
| Audi | Q5 | 2.0 16v TDI quattro S-Tronic | CAHB | Diesel | 120 | 161 | 2014 | TCM | Temic |
| Audi | Q5 | 3.0 V6 24v TDI quattro S-Tronic | CCWA | Diesel | 176 | 236 | 2008 | TCM | Temic |
| Audi | Q5 | 3.0 V6 24v TDI quattro S-Tronic | CDUD | Diesel | 180 | 241 | 2011 | TCM | Temic |
| Audi | Q5 | 2.0 16v TFSI quattro S-Tronic | CDNC | Petrol | 155 | 208 | 2008 | TCM | Temic |
| Audi | Q5 | 3.0 V6 24v TFSI quattro S-Tronic | CTVA | Petrol | 200 | 268 | 2012 | TCM | Temic |
| Audi | Q5 | 3.0 V6 24v TFSI quattro S-Tronic | CTUC | Petrol | 200 | 268 | 2012 | TCM | Temic |
| Audi | Q5 | 3.2 V6 24v FSI quattro S-Tronic | CALB | Petrol | 199 | 267 | 2008 | TCM | Temic |
| Audi | S4 | 3.0 V6 TFSI Quattro 7AT | CAKA | Petrol | 245 | 329 | 2008 | TCM | Temic |
| Audi | S4 | 3.0 V6 TFSI Quattro 7AT | CCBA | Petrol | 245 | 329 | 2009 | TCM | Temic |
| Audi | S4 Avant | 3.0 V6 TFSI Quattro 7AT | CAKA | Petrol | 245 | 329 | 2008 | TCM | Temic |
| Audi | S5 | 3.0 V6 24v TFSI quattro S-Tronic | CAKA | Petrol | 245 | 329 | 2009 | TCM | Temic |
| Audi | S5 | 3.0 V6 24v TFSI quattro | CGWC | Petrol | 245 | 329 | 2011 | TCM | Temic |
| Audi | S5 | 3.0 V6 24v TFSI quattro | CGXC | Petrol | 245 | 329 | 2012 | TCM | Temic |
| Audi | S5 | 3.0 V6 24v TFSI quattro | CTDA | Petrol | 245 | 329 | 2014 | TCM | Temic |
| Audi | S5 | 3.0 V6 24v TFSI quattro | CREC | Petrol | 245 | 329 | 2014 | TCM | Temic |
| Audi | S5 | 3.0 V6 24v TFSI quattro | CGWC | Petrol | 245 | 329 | 2011 | TCM | Temic |
| Audi | S5 | 3.0 V6 24v TFSI quattro | CTDA | Petrol | 245 | 329 | 2014 | TCM | Temic |
| Audi | S5 | 3.0 V6 24v TFSI quattro | CREC | Petrol | 245 | 329 | 2014 | TCM | Temic |
| Audi | S5 | 3.0 V6 24v TFSI quattro S-Tronic | CAKA | Petrol | 245 | 329 | 2010 | TCM | Temic |
| Audi | S6 | 4.0 V8 TFSI Quattro | CEUC | Petrol | 309 | 414 | 2012 | TCM | Temic |
| Audi | S7 | 4.0 V8 32v TFSI Quattro | CEUC | Petrol | 309 | 414 | 2012 | TCM | Temic |
| Porsche | Macan S Diesel | 3.0 V6 Turbo 7AT | MCT.BB | Diesel | 155 | 208 | 2014 | TCM | Temic |
| Porsche | Macan S Diesel | 3.0 V6 Turbo 7AT | MCT.BC | Diesel | 184 | 247 | 2014 | TCM | Temic |
| Porsche | Macan S Diesel | 3.0 V6 Turbo 7AT | MCT.BA | Diesel | 190 | 255 | 2014 | TCM | Temic |
Cummins Hyundai Truck Continental CM2350A CAN
KESSv2 –Prt588
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K226
Cummins Autosan Truck Continental CM2150E CAN
KESSv2 –Prt591
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300KCAN
Cummins PeterbiltTruck Motorola CM875 CAN
KESSv2 –Prt592
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K226
Cummins BCI Truck Motorola CM850 CAN
KESSv2 –Prt594
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K235
Cummins International Truck Motorola CM876 CAN
KESSv2 –Prt598
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K235
Cummins Alexander-Dennis Truck Motorola CM850 CAN
KESSv2 –Prt601
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K235
Cummins Freightliner Truck Recon CM2150E CAN
KESSv2 –Prt603
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300KCAN
Cummins GVM Tractor Motorola CM850 CAN
KESSv2 –Prt586
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K226
CumminsHuddingTractor Continental CM2250 CAN
KESSv2 –Prt597
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K226
Cummins Hagie Tractor Motorola CM850 CAN
KESSv2 –Prt599
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K226
Cummins Crary Tractor Motorola CM850 CAN
KESSv2 –Prt600
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K226
Cummins John Deere Tractor 2350A
KESSv2 –Prt602
– Read: YES
– Write: YES
– Checksum Correction: YES
– Direct Connection:144300K226
Credits tohttp://www.alientech-tools.com/en/k-suite-2-35/
Kess V2Ksuite2.35 download free online?:
-Better NOT.Ksuite2.35 is tested with somekessv2 master, NOT ALL OK.
Here are Kess V2 (Truck) FW 3.099/4.036/4.024tested without any issue:
se87-e:KESSV2 Firmware V3.099
se87-c:KESS V2 Firmware V4.036
se87-ck:Truck Version KESS V2 Master Firmware V4.036
se87-k:Truck Version KESS V2 Firmware V4.024
se87-d:KESSV2 Firmware V4.036 NO Tokens Limitation
se87:KESSV2 Master with new LPC2478 Chip
Note: for other versions ofkessv2 programmer, you are tryingonyour own risk!
Kess V2 2.35tested (readecudata) no issues on BMW E90 2005:
Kess v2 2.35 read E90ecudata successfully!
Source:http://blog.obdexpress.co.uk/2017/07/05/kess-v2-2-35-car-list-tested-ok-on-bmw-e90/
Posted by: OBDexpress.co.uk at
08:50 AM
| No Comments
| Add Comment
Post contains 3833 words, total size 94 kb.
July 04, 2017
TheVgates can OBD II Diagnostic Scanner VS890sallows you to access your OBD II vehicle’s data which was only available to dealership technicians using expensive proprietary scan tools.
Now it's available to every people who has a
Vgate VS890S Supports 13 languages:
English Spanish Portuguese Korean Japanese Italian
Vgate VS890SFeatures & Functions:
Works with all 1996 and later OBDII compliant US, European and Asian vehicles.
Support manually input DTC Lookup. This operation will erase all DTCs, Freeze Frame Data, Oxygen sensor
Read Diagnostic Trouble Codes(DTCs)
Clear trouble codes
View real-time vehicle operation data (
View Freeze Frame data
View I/M readiness
Read O2 Monitor Test data
Read On-Board Mon.Test
Component Test
View the vehicle’s information
Modules Present
Unit of Measure
State Emission
Read All DTCs
Read Stored DTCs
Detailed help information
Capable of showing probable
Up to 161 data items, each of them is with online help information.
Reset engine MIL.
This operation will erase all DTCs, freeze frame Data, oxygen sensor
Vgate VS890S Specifications:
LCD:2.4 inch VA STN 128*64, wide visible area and high contrast
The contents are readable even in strong sunshine.
Harmless fade-resistant paint
Rubber oil sprayed outer cover,
CE,FCC,
Package List:
1pc x Vgate OBD II Diagnostic Scanner VS890s
Posted by: OBDexpress.co.uk at
01:39 AM
| No Comments
| Add Comment
Post contains 263 words, total size 14 kb.
32 queries taking 0.0507 seconds, 147 records returned.
Powered by Minx 1.1.6c-pink.
